Table 3. Server Chassis Features (Lx Sku) - Intel SC5400LX User Manual

Table 3
Dimensions
Hard Drives
Peripherals
Control Panel (dependent
on option selected)
LEDs and displays
(dependent on option
selected)
Power Supply
Fans
USB 2.0
Video
4
summarizes the features of the LX SKU.

Table 3. Server Chassis Features (LX SKU)

Feature
•
•
•
•
One fixed drive bay for up to six fixed SAS or SATA drives.
Optional hot-swap drive bays:
•
•
An optional four-drive fixed drive bay is also available.
•
•
•
•
With Front Control Panel:
•
•
•
•
•
•
One redundant capable 830-W power supply module with an
integrated cooling fan. Optional second redundant power supply
module is available.
Four hot-swap, redundant chassis fans:
•
•
•
•
•
•
Description
16.6 inches high (Pedestal: 17 inches)
8.6 inches wide
27.4 inches deep (Pedestal: 28.4 inches)
36.2 kilograms
Six-drive SAS/SATA
Four-drive SAS/SATA
Supports up to ten drives
Three multi-mount 5.25-inch peripheral bays
Front Control Panel
®
Intel Local Control Panel (optional)
NIC1 Activity
NIC2 Activity
Power / Sleep
System Status
System Identification
Hard Drive Activity
Two 120-mm fans
Two 92-mm fans
Two front panel USB ports with Front Control Panel
Four back panel USB ports
One front panel video port (available only with Standard Control
Panel)
One rear panel video port
Intel® Server Chassis SC5400 User's Guide
