Connect LCP Cable to LCP Header on Server Board
1. Connect the LCP cable to the LCP header on the server board.
2. For an Intel® Server Board S5000VSA, use header J1J6 on the server board.
Figure 32. Attaching LCP Cable to Header on Intel® Server Board S5000VSA
3. For an Intel® Server Board S5000PSL or Intel® Server Board S5000XVN, use
header J2J1 on the server board.
Figure 33. Attaching LCP Cable to Header on Intel® Server Board S5000PSL or Intel®
Local Control Panel Kit Install Guide
Local Control Panel Kit Installation Instructions
Server Board XVN
AF00569
AF00570
23
