QWIK-PURE CS
®
Degree of
soiling
Heavily soiled
collector,
deposits and large
amounts of oil in
collector
52 | 68
Figure Description / explanation
Preparation work:
1. The product must have been shut down.
2. The assembly you will be cleaning must
3. Bring the assembly unit to be cleaned to
Cleaning:
1. Open the cap (if any) on the collector's
2. Mix tap water with dish detergent and pour
3. Carefully shake the collector, with the outlet
4. Pour fresh water into the collector and let
5. Close the collector's outlet with the cap.
Concluding work:
1. Install the product with new cartridges
Installation and operating manual
have been disassembled (please refer to
section "12. Disassembly" on page 57).
a washing station with an integrated oil
separator.
outlet and empty the collector.
0 Collect or siphon off the condensate.
it into the outlet.
pointing up, until the deposits come loose.
0 Please note that you might need
a second person to help with this
depending on the collector's size and
weight.
it drain out multiple times until you get the
desired cleaning results.
0 Collect the resulting flushing water and
dispose of it separately.
(please refer to section "9.3.2 Replace filter
cartridges" on page 43).
