Installation and operating manual
Figure
Installation work
Description / explanation
14. Check the sealing surfaces in the connecting pipe
for damage and dirt.
0 Remove any dirt.
0 If there is any damage, contact the
manufacturer's service department (please
refer to section "1.1 Contact" on page 4).
15. Insert the connecting pipe into the connection
for the pressure relief chamber.
0 Point the connecting pipe's drain valve
downwards.
16. Align the connecting pipe's connection with the
filter cartridge's connection.
17. Insert the connecting pipe into the filter
cartridge connection.
18. Slide the bayonet mounts over the connections
and turn them all the way clockwise.
QWIK-PURE CS
®
33 | 68
