4.3 Materials
Component
Filter cartridge
Pressure relief chamber
Condensate inlet
Connecting pipe
Clean water tank
Foot
Collector
4.4 Dimensions
No. [mm]
[X1]
[X2]
[X3]
[Y1]
[Y2]
X1
X2
[in]
625 24.61
600 23.62
-- --
-- --
540 21.26
Material
Plastic blend and cellulose
PE
PA/PP/VA
PE
PE
PE
PE
No. [mm]
[Y3] 1482
[Y4] 1408
[Y5] 722
[Y6] 639
[Y7] 327
QWIK-PURE CS
®
[in]
58.35
55.43
28.43
25.16
12.87
