Installation and operating manual
Figure
Installation work
Description / explanation
5. Align the locking device with the heel facing
downwards and insert it into the locking device
opening in the collector.
6. Press the locking device into the locking device
opening as far as it will go.
QWIK-PURE
CS
®
29 | 68
