- Page 1 Operating Manual Flanged Water Separator ® CLEARPOINT Flange Water Separator Series Models L100 to L200 READ MANUAL FIRST BEFORE INSTALLATION AND OPERATION...
-
Page 2: Table Of Contents
Table of Contents DEFINITION OF THE SAFETY SYMBOLS WARNINGS INTRODUCTION RECEIVING AND TRANSPORTING SAFETY RULES AREAS OF APPLICATION TECHNICAL SPECIFICATIONS OVERVIEW DIMENSIONS FUNCTION INSTALLATION SITE POSITIONING: INSTALLATION: CLEARPOINT W L100- L200... -
Page 3: Definition Of The Safety Symbols
DEFINITION OF THE SAFETY SYMBOLS Before attempting any Electrical Hazard: General Warning: Warning: Warning: Warning: service, please read the Possibility of Risk of damage or injury Under pressure High temperature Non-breathable air manual electrocution Warning: Warning: Warning: Warning: Warning: Operations that can be Do not operate if parts Hearing All work to be... -
Page 4: Introduction
In the interest of further development, BEKO TECHNOLOGIES reserves the right to implement changes at any time, while retaining the essential features of the device, if such changes become necessary to enhance the technical capacity of the device for reasons of safety or standard commercial practice. -
Page 5: Receiving And Transporting
RECEIVING AND TRANSPORTING CLEARPOINT® water separators undergo stringent quality control procedures in the manufacturing plant and are handed over to the forwarding agent in perfect condition. Upon arrival of the goods, please check for any visible damage and, where appropriate, insist on a corresponding note on the delivery receipt. Get in touch with the forwarding agent and arrange for an assessment of the damage. -
Page 6: Areas Of Application
• In the event of leaks, shut off the compressed air supply immediately and eliminate the cause in order to maintain safe and cost-effective operation. • CLEARPOINT® water separators, including accessories, must be checked once a week. This applies in particular to the function of the drain. -
Page 7: Dimensions
DIMENSIONS 1. Air connection 2. Data plate 3. Condensate drain connection FUNCTION The separator housings are equipped with internal swirl inserts, which causes air entering at high speed to be invested with a rapid rotation motion. The acceleration this causes produces a large centrifugal force on the particles and droplets within the compressed air, which propels them on the outer wall. -
Page 8: Installation Site
INSTALLATION SITE Serious consideration should be given when selecting the installation site for the water separator, as an improper location could directly affect the proper operation of the water separator. This unit is not suitable to be used in explosive atmospheres, where risk of fire could exist, in the presence of gaseous or solid pollutants or in outdoor applications or areas exposed to the elements. - Page 9 DO NOT DISPOSE OF THE CONDENSATE INTO THE ENVIRONMENT The condensate collected in the water separator contains oil particles released into the air stream by the compressor. Dispose the condensate in compliance with all local, state and Federal rules and regulations. We highly recommend the installation of either a QWIK-PURE®...
- Page 10 For technical product support please call +1 (800) 235-6797 and select Option 2 CLEARPOINT® Flange Water Separators...
