Status Bar

In addition to providing a screen refresh button, the status bar (Figure 3-3) at the
bottom of the LC provides the following information:
• Whether there are any System Messages
• When the screen was last refreshed
• The currently logged-in user and the group to which the user belongs
• The library's IP address (on the LC) or library name (on the RLC)
Refresh Messages Time and date of last refresh
Figure 3-3 The status bar as it is displayed on the LC.
Last Refresh
The date and time shown after Valid as of indicate the last time that the screen was
refreshed. The screen can be set to refresh at designated intervals (see Refresh Rate on
page 83), or the user can refresh it as needed by selecting the Refresh button.
Messages Icons
The Messages icon shows the status of library components, using these designations:
Symbol
Library Name or IP Address
The status bar on the LC shows the library's IP address; the status bar on the RLC
shows the library's name (see Library Name on page 84).
User and Group
The status bar shows the name of the user currently logged in, and, next to it in
parentheses, the user's security group (see Group Privileges/Security on page 80).
Chapter 3. Initial Configuration
Description
A check mark in green
i
An in blue
An exclamation point in yellow Check messages for component status.
An X in red
Current user User's group
Meaning
Component is functioning correctly.
Check messages for information.
Check messages for component error.
34
IP address (or name)
