as for the IP Address. A value of 0.0.0.0 indicates that no default gateway is
defined.
Socket Port: This value indicates the port number corresponding to the
Raw-socket service.
The operation steps to configure are as follows.
This configures the instrument address (IP Mode).
Reset the LAN to the Default Settings
The operation steps to reset the LAN to the default settings are as follows.
1. Press [Shift]+[I-set] (
2. Use left/right key or rotate the knob to select Config >
3. Use left/right key or rotate the knob to select LAN and press [Enter] to
4. Use left/right key or rotate the knob to select Restore and press [Enter] to
5. After the setting is completed, press [Esc] to exit.
6. Restart the instrument and the modified configuration item will take effect.
Using the Web Server
The instrument provides a built-in Web server that allows you to monitor and
control the instrument directly from your computer's Web browser. To use the
Web server, you need to interconnect the instrument and your computer via
1. Press [Shift]+[I-set] (
2. Use left/right key or rotate the knob to select Config >
and press [Enter] to confirm.
Communication
3. Use left/right key or rotate the knob to select LAN and press [Enter]
to confirm.
4. Use left/right key or rotate the knob to select Config and press [Enter]
to confirm.
The first displayed menu item IP Mode is to configure the instrument
address.
5. Press [Enter] to confirm.
– DHCP: automatically configure the addressing of the instrument;
– Manual: manually configure the addressing of the instrument.
6. After the setting is completed, press [Esc] to exit.
7. Restart the instrument and the modified configuration item will take
effect.
and press [Enter] to confirm.
confirm.
confirm.
– NO: indicates refuse to reset the LAN to the default settings.
– YES: indicates reset the LAN to the default settings.
Copyright © Itech Electronic Co., Ltd.
) to enter into the menu setting interface.
Menu
) to enter into the menu setting interface.
Menu
Communication with PC
