2.2 Introduction to the Front Panel
1. VFD display
2. Rotary knob
3. Power switch, Local and Shift key
4. Numeric keys and ESC escape key
5. Function keys
6. Up/Down/Left/Right keys
7. DC output terminals of CH1 and CH2 (max. 10A), ground terminal
2.3 Introduction of the Keypad
The keys are described in the table below:
Key Symbol
0-9
.
Name & Function
Numeric keys (1~2 are single output on/off keys to be
used in conjunction with the
LOCK status).
Escape from the current setting or menu item.
Decimal point
Copyright © Itech Electronic Co., Ltd.
Quick Start
(Shift) key, except for
