ITech IT6341C User Manual page 39

The Save Read function will be Disable after selecting the Serial Parallel or
Synchronized state.
Note
3.13 IT6341C Survey and Measure
CH1 range is 5V, 16A, the terminal on the front panel can withstand a
maximum current of 10A, if you need to measure more than 10A current,
please be sure to connect the green output terminal on the rear panel.
After changing the series/parallel state, all channels will be OFF and all voltage values
will change to 0V, you have to reset the output parameters. The channel which is
selected as series/parallel or synchronized state will be added with [ ] display in the
menu.
The Save and Recall functions are disabled after a serial parallel connection or
synchronization. Selecting Serial Parallel requires a hardware connection to be valid.
Copyright © Itech Electronic Co., Ltd.
Function and Features
30
