Mounting a Holder
1 2
27.05.2024
NOTICE
All holders are supplied with pre-fitted screws. If a test tube holder
or box for microtitre plates is placed on the Sticky Stuff adhesive
matting, there is a risk that the adhesive matting is damaged by
protruding screws.
Remove the screws before you place test tube holders or microtitre
plates on the Sticky Stuff adhesive matting.
Clamps, test tube holders and boxes for microtitre plates are fixed to
the tray using screws. The device is delivered with pre-fitted screws.
The screws are each secured with one flat gasket at the bottom so
that they cannot fall out. Only use the screws provided or screws of
the same size for mounting.
To mount a holder, proceed as follows:
1. Loosen the flat gaskets (1).
2. Position the holder on the tray.
3. Centre a screw (2) on the threaded hole in the tray and screw it
in loosely. It must still be possible to turn the holder.
4. Align the holder so that all screws are vertical above the respec-
tive threaded hole in the tray.
5. Insert the screws loosely. Ensure that the screws are screwed in
straight and do not tilt.
6. Evenly tighten all screws cross-wise.
