5.1.2 Tray with Steel Clamps
5.1.3 Tray with Pin Holders
Overview
27.05.2024
Fitting identical clamps on the entire tray results in the following
capacities:
Flask size [mL]
25
50
100
250
300
500
1000
2000
3000
4000
5000
For applications in which large numbers of microtitre or deep-well
plates need to be incubated, various trays with pin holders are avail-
able. These enable loading with several layers of microtitre and deep-
well plates.
The plates can be stacked. This allows you to simultaneously incubate
up to 72 deep-well plates and up to 144 microtitre plates on one M
tray.
The trays are designed for plates with the dimensions 85.1 x 127 mm.
To ensure the cultures receive the optimum oxygen supply, spacers
can be placed between stacked plates. It is available in two variants:
Multitron - Operating manual
Accessories
Number of flasks per M tray
197
131
91
48
43
31
19
13
9
8
6
Ring spacers (10 mm high) are placed
on the pins individually. Depending on
the type of tray loading, this makes it
possible to remove individual plates or
stacks of plates.
