Projector Connections
c
Connect the other end to the streaming media player.
Connecting to an eARC/ARC Compatible AV System or
External Speakers
If your AV system or speakers, such as a sound bar, has an HDMI port, you can
connect them to the projector using an HDMI cable (with Ethernet) to output
audio to these devices.
• When the AV System is connected to the projector, set HDMI Link to
On.
Signal I/O > HDMI Link > HDMI Link
s
• See the Supplemental A/V Support Specification for eARC/ARC audio
supported formats.
a
Connect the HDMI cable to your AV system's or speakers' HDMI output
port (eARC/ARC compatible).
b
Connect the other end to the projector's HDMI2 (eARC/ARC) port.
c
Make any necessary settings on the connected AV system. See your
device's documentation for more information.
Related Links
g
• "Getting the Latest Version of the Documents"
31
