Epson EH-QB1000B Quick Setup

EH-QB1000B/EH-QB1000W
Quick Setup
IMPORTANT: Before using this product, make sure you read these instructions
and the safety instructions in the online User's Guide.
Note: Your product may differ from the illustrations on this sheet, but the
instructions are the same.
Choose a location
Keep the projector level and place it at a height so its lens is even with the top
or bottom of the screen and is centered horizontally. If this isn't possible, use the
lens shift feature to reposition the image (see "Adjust the image").
See the online User's Guide for more information on where to place your
projector.
Connect the projector
Connect multiple video devices and use the Source buttons on the remote
control or the Source button on the projector to switch between them. For
additional connection types, see the online User's Guide.
Streaming
Power supply
device
USB cable
Note:
• When projecting images at 4K 120Hz, use an HDMI 2.1 rated cable (ultra-high
speed).
• You can output audio to an external sound system that supports
using the HDMI 2 (eARC/ARC) port.
™
• If you are connecting an optical HDMI cable that has a power supply USB cable,
you must also connect the cable's USB power connector to the Opt.HDMI
(300mA) port.
Wired network
Connect the projector to your network using an Ethernet cable. See "Wired
network configuration" for more information.
Turn on your equipment
1
Plug in the projector.
HDMI cable
TM
™
Ethernet cable
2
Press the power button on the projector or the On button on the
remote control. The shutter opens and the
then stays on.
Note: To shut down the projector, press the
projector or the Standby button on the remote control, then press the
button again to confirm, if necessary. Wait for cooldown to complete
before unplugging the projector.
3
Use the arrow and Enter buttons on the remote control to select the focus,
image orientation, and language settings.
Note: To change these settings, see the online User's Guide.
4
Turn on your video source.
5
If you don't see an image, press one of the Source buttons on the remote
control to select the image source.
Note: If you still see a blank screen or have other display problems, see the
troubleshooting tips on this sheet.
Using the remote control
Install the batteries as shown (two AA batteries).
Turn projector on
Choose which source to
display
Control connected
sources with HDMI
Link
Adjust zoom, focus,
and lens shift
Access projector menus
For more information on using the remote control, see the online User's Guide.
power light flashes blue,
power button on the
Turn projector off
Turn off projector
display
Navigate projector
menus
