Adjusting the Color Convergence (Panel Alignment)
g
Select one of the following options:
• Select Shift the whole panel to adjust the entire panel at the same time
and go to the next step.
• Select Adjust the four corners to adjust the corners of the panel one at
a time and go to step 10.
h
Use the arrow buttons on the remote control to adjust the color alignment
selected in Select Color, and then press [Enter].
Adjustment affects the grid lines in the entire screen.
i
Select one of the following options:
• Select Adjust the four corners to fine-tune your adjustments.
• Select Exit to finish adjustments.
j
Use the arrow buttons on the remote control to adjust the color alignment
of the screen corner highlighted by the orange box, and then press [Enter].
k
When you are finished adjusting each corner of the screen, press [Enter].
l
Select one of the following options:
• If your projector needs additional panel alignment, select Select
intersection and adjust. Use the arrow buttons on the remote control
to highlight the corner of any misaligned box on the screen, press
[Enter], make any necessary adjustments, and then press [Enter] again.
Repeat this step as necessary for the other intersections.
• Select Exit to finish adjustments.
