Page 1 User's Guide...
Page 2 Contents Notations Used in This Guide Connecting to a Computer for HDMI Video ............28 Connecting to External USB Devices ..............29 USB Device Projection ..................29 Using the Manual to Search for Information ........7 Connecting to a USB Device ................. 29 Searching by Keyword ..................
Page 3 Switching to Content Playback Mode ............... 87 Resizing the Image with Digital Zoom ..........62 Projecting Your Playlists .................. 88 Creating Playlists Using Epson Web Control ........... 88 Adjusting the Image Position Using Image Shift ......63 Adding Effects to Your Projected Image ............90 Selecting an Image Source ..............65...
Page 4 Contents Setting Projector Event Schedules ..........114 Cleaning the Projection Window ............142 Cleaning the Obstacle Sensor ............143 Adjusting the Menu Settings Cleaning the Projector Case ............144 Air Filter and Vent Maintenance .............145 Using the Projector's Menus ............118 Cleaning the Air Filter ................... 145 Using the Displayed Keyboard ............
Page 5 Supported Monitor Display Resolutions ........174 Projector Specifications ..............175 Connector Specifications ................175 External Dimensions ............... 176 Supported Features for Epson Projector Content Manager ..177 List of Safety Symbols and Instructions ........178 Laser Safety Information ..............180 Laser Warning Labels ..................180 Glossary ....................183...
Page 6 Notations Used in This Guide Safety Symbols The projector and its manuals use graphical symbols and labels to indicate content that tells you how to use the projector safely. Read and carefully follow the instructions that are marked with these symbols and labels to avoid injury to persons or damage to property. This symbol indicates information that, if ignored, could possibly result in personal injury or even death.
Page 7 Using the Manual to Search for Information The PDF manual allows you to search for information you are looking for by keyword, or jump directly to specific sections using the bookmarks. You can also print only the pages you need. This section explains how to use a PDF manual that has been opened in Adobe Reader X on your computer.
Page 8 Getting the Latest Version of the Documents You can get the latest version of the manuals and specifications on the Epson Web site. Visit epson.sn, and enter your model name.
Page 9 Introduction to Your Projector Refer to these sections to learn more about your projector's features and part names. Related Links • "Projector Features" p.10 • "Projector Parts and Functions" p.11...
Page 10 This projector comes with these special features. Refer to these sections for more Quick and Easy Setup details. • You can use the Epson Setting Assistant application on a smart phone or Related Links tablet that has a camera function to correct distortion more easily.
Page 11 Projector Parts and Functions The following sections explain the projector parts and their functions. Name Function Air filter cover Open to access the air filter. Related Links • "Projector Parts - Front" Air filter cover latch Slide to remove the air filter cover. p.11 •...
Page 12 Projector Parts and Functions Projector Parts - Top/Side Name Function Projection window Images are projected from the lens inside the projector. Warning • Do not look into the projection window while projecting. • Do not place any objects or put your hand near the projection window.
Page 13 Projector Parts and Functions • "Cleaning the Projection Window" p.142 Name Function • "Air Filter and Vent Maintenance" p.145 Wire clamp fixing When you use the optional setting plate or ceiling • "Projector Parts - Control Panel" p.15 point mount, fix the carabiner here to attach the safety wire •...
Page 14 Projector Parts and Functions Related Links Name Function • "Air Filter and Vent Maintenance" p.145 • "Installing a Security Cable" Use to connect a USB memory device or digital camera USB-A ( p.96 for projecting movies or images using the PC Free port (USB-A2) feature or in Content Playback mode.
Page 15 Projector Parts and Functions • "Adjusting the Menu Settings" p.117 Projector Parts - Control Panel • "Home Screen" p.39 • "Selecting an Image Source" p.65 Name Function Turns the projector on or off. Power button [ [Menu] button Displays and closes the projector's menu. Volume buttons Adjusts the volume of any external speakers.
Page 16 Projector Parts and Functions Projector Parts - Remote Control Name Function [Standby] button Turns the projector off. [HDMI1]/[HDMI2] Switches the image source between the HDMI1 and button HDMI2 (eARC/ARC) ports. [Information] button Displays the Information screen. [Light Output] button Displays the Brightness Level screen. Playback control Controls playback of the connected devices that support buttons...
Page 17 Projector Parts and Functions Name Function [Esc] button Stops the current function. Moves back to the previous menu level while displaying the projector's menu. [Image Enh] button Displays the Image Enhancement screen. Displays the Aspect screen. [Aspect] button [USB] button Switches the image source to the USB-A port.
Page 18 Setting Up the Projector Follow the instructions in these sections to set up your projector. Related Links • "Projector Placement" p.19 • "Installing the Safety Wire" p.23 • "Projector Connections" p.28 • "Wired Network Connection" p.32 • "Attaching and Removing the Side Cover" p.34 •...
Page 19 Projector Placement You can install the projector on a wall or ceiling, or place it on a table to project You can adjust distortion and the height of the projected image using the images. front adjustable feet and rear adjustable foot. To install the projector on a wall or mount the projector from a ceiling, you can use an optional mount or a commercially available mount compatible with the VESA Mounting Interface Standard (100 ×...
Page 20 • When installing the projector in a high position, take measures to prevent falling fall. After installing the specific Epson mount that supports your projector, make by using wires to ensure safety in an emergency, such as an earthquake, and to sure you secure the mount to all of the projector's ceiling mount fixing points.
Page 21 Projector Placement Precautions on Installation Attention • If the projector is installed at an angle, it should be installed by qualified technicians using mounting hardware designed for use with this projector. • Install the projector appropriately to prevent it from falling down. •...
Page 22 Projector Placement Installation space Installation space (When installing multiple projectors side by side) Attention Attention Be sure to leave the following amount of space around the projector so as not to • If you are installing multiple projectors next to each other, make sure hot air from block the air exhaust and intake vents.
Page 23 ( ) on the projector. Warning Be sure to use the safety wire provided with the Epson ceiling mount. The safety wire is available as an optional Safety Wire Set ELPWR01. Related Links •...
Page 24 Installing the Safety Wire Tighten the carabiner lock. Attach the wire clamp to the carabiner, and then use the screw to fix the wire clamp to the screw into the wire clamp fixing point ( ) on the projector. When Using the Ceiling Mount ELPMB30 You can attach a safety wire to your projector for increased safety as shown.
Page 25 Installing the Safety Wire Tighten the carabiner lock. Attach the wire clamp to the carabiner, and then use the screw to fix the wire clamp to the screw into the wire clamp fixing point ( ) on the projector. When Using the Setting Plate ELPMB75 You can attach a safety wire to your projector for increased safety as shown.
Page 26 Installing the Safety Wire Pass the other carabiner through the hole in the arm of the setting plate. Loop the safety wire through the carabiner attaching it to the setting plate.
Page 27 Installing the Safety Wire Tighten the carabiner lock.
Page 28 Projector Connections See these sections to connect the projector to a variety of projection sources. • If the port on the device you connect has an unusual shape, use the cable supplied with the device or an optional cable to connect to the Attention projector.
Page 29 Projector Connections Connect the other end to one of the projector's HDMI ports. • Digital cameras or smartphones must be USB-mounted devices, not TWAIN-compliant devices, and must be USB Mass Storage Class- compliant. • USB hard drives must meet these requirements: •...
Page 30 Projector Connections Connecting to a Streaming Media Player Connect the USB cable or USB flash drive to the projector's USB-A port as shown. You can connect your streaming media player to the projector's HDMI port. By connecting the power supply USB cable, you can power the streaming media player from the projector.
Page 31 Projector Connections Connect the other end to the streaming media player. Connect the other end to the projector's HDMI2 (eARC/ARC) port. Make any necessary settings on the connected AV system. See your Connecting to an eARC/ARC Compatible AV System or device's documentation for more information.
Page 32 Wired Network Connection You can monitor and control your projector, over a network. Make sure you already connected the projector to your wired network using the LAN port. To perform these operations, connect the projector to your network, and then set up your projector and computer.
Page 33 Wired Network Connection Select the Wired LAN menu and press [Enter]. Assign the IP settings for your network as necessary. • If your network assigns addresses automatically, select IP Settings to set the DHCP setting to On. • If you must set addresses manually, select IP Settings to set the DHCP setting to Off, and then enter the projector's IP Address, Subnet Mask, and Gateway Address as necessary.
Page 34 Attaching and Removing the Side Cover You can attach the side cover to hide the attached cables from view. Caution Do not bundle the power cord to the other cables. Otherwise, a fire may occur. Remove the side cover from the projector. Replace the side cover.
Page 35 Installing Batteries in the Remote Control The remote control uses the two AA batteries that came with the projector. Insert the batteries with the + and – ends facing as shown. Attention Make sure you read the Safety Instructions before handling the batteries. Replace the batteries as soon as they run out.
Page 36 Remote Control Operation The remote control lets you control the projector from almost anywhere in the room. Make sure that you aim the remote control at the projector's receivers within the distance and angles listed here. Avoid using the remote control in conditions with bright fluorescent lights or in direct sunlight, or the projector may not respond to commands.
Page 37 Using Basic Projector Features Follow the instructions in these sections to use your projector's basic features. Related Links • "Turning On the Projector" p.38 • "Turning Off the Projector" p.41 • "Setting the Date and Time" p.42 • "Selecting the Language for the Projector Menus" p.45 •...
Page 38 Turning On the Projector Turn on the computer or video equipment you want to use after you turn on the Connect the power cord to the projector's power inlet and plug it into an projector. electrical outlet. Remove the side cover. Warning Be sure to connect to ground before plugging in.
Page 39 Turning On the Projector • When you turn on the projector for the first time, the initial • When the Direct Power On setting is set to On in the projector's setup wizard is displayed. Follow the instructions on the initial Operation menu, the projector turns on as soon as you plug it in.
Page 40 Turning On the Projector Selects the source you want to project. A check mark appears on the upper right of the current input source. You can check a preview of the current input image for most sources as a thumbnail (other than the USB input source in Content Playback mode). Lets you select the following common projector settings (settings may vary depending on other selected settings): •...
Page 41 Turning Off the Projector Turn off the projector after use. • Turn off this product when it is not in use to prolong the life of the projector. Light source life varies depending on the mode selected, environmental conditions, and usage. Brightness decreases over time. •...
Page 42 Setting the Date and Time You can set the date and time for the projector. Select the Date & Time setting and press [Enter]. You see this screen: Turn on the projector. Press the [Menu] button on the control panel or remote control. Select the Date &...
Page 43 Setting the Date and Time Select Time, press [Enter], and use the displayed keyboard to enter the To activate daylight saving time, select the Daylight Saving Time setting and set it to On. Then select settings. current local time. To set the Time Difference (UTC) as explained in step 8, enter Coordinated Universal Time instead of the current local time.
Page 44 Setting the Date and Time To update the time automatically through an Internet time server, select the Internet Time setting and set it to On. Then select settings. When you are finished, select Set and press [Enter]. Press [Menu] or [Esc] to exit the menus.
Page 45 Selecting the Language for the Projector Menus If you want to view the projector's menus and messages in another language, Select the Management setting and press [Enter]. you can change the Language setting. Turn on the projector. Press the [Menu] button on the control panel or remote control. Select the Language setting and press [Enter].
Page 46 Changing the Projection Mode Depending on how you positioned the projector, you may need to change the Select the Installation menu and press [Enter]. projection mode so your images project correctly. • Front lets you project from a table in front of the screen. •...
Page 47 Setting the Screen Type You can use the Screen Type setting to match the aspect ratio of the displayed Select the Installation menu and press [Enter]. image to the screen you are using. • You cannot change the Screen Type setting when the Content Playback setting is set to On in the projector's Operation menu.
Page 48 Setting the Screen Type Press [Menu] to exit the menus. Press the [Menu] button on the control panel or remote control. You need to restart the projector. Follow the on-screen instructions. Adjust the aspect ratio for the projected image, if necessary. When the Screen Type setting changes, the EDID settings are automatically adjusted.
Page 49 Setting the Screen Type Use the arrow buttons on the control panel or remote control to adjust the position of the image. When you are finished, press [Menu].
Page 50 Adjusting the Image Height If you are projecting from a table or other flat surface and the image is too high or low, you can adjust the image height using the projector's adjustable feet. The larger the angle of tilt, the harder it becomes to focus. Locate the projector on a level surface so that it only needs to be tilted at a small angle.
Page 51 Displaying a Test Pattern You can display a test pattern to adjust the projected image. Some settings may not be available while displaying a test pattern. To adjust these settings, project an image from a connected device. Turn on the projector. Press the [Pattern] button on the remote control.
Page 52 Focusing the Image Using the Focus Lever You can correct the focus using the focus lever. Move the focus lever to adjust the focus. Turn on the projector and display an image. Remove the side cover. Replace the side cover. Focus the following part on the screen.
Page 53 You can correct distortion in the projected image by following the on-screen instructions from the Installation menu. To correct distortion more easily, you can use the Epson Setting Assistant application on a smart phone or tablet that has a camera function. Install the application by using the QR code displayed on the projected screen.
Page 54 Image Shape Correcting the Image Shape with Quick Corner Select the Geometry Correction Wizard, and press [Enter]. You can use the projector's Quick Corner setting to correct the shape and size of an image that is unevenly rectangular. If you change the Screen Type and Screen Position settings, the Follow the on-screen instructions to correct distortion in the image.
Page 55 Image Shape Select the Installation menu and press [Enter]. Select Quick Corner and press [Enter]. Then select Yes and press [Enter] if necessary. You see the area selection screen. Select Geometry Correction and press [Enter].
Page 56 Image Shape Use the arrow buttons to select the area of the image you want to adjust. • You can also select the area by pressing the following numeric Then press [Enter]. buttons on the remote control: • [1] selects the upper left area. •...
Page 57 Image Shape Press the [Menu] button on the control panel or remote control. To save the current shape of an image you have adjusted, select Save Memory. You can save up to three image shapes in the memory. Installation > Geometry Correction > Memory > Save Memory Correcting Image Shape with Arc Correction You can use the projector's Arc Correction setting to adjust the shape of an image projected on a curved or spherical surface.
Page 58 Image Shape Select Arc Correction and press [Enter]. Use the arrow buttons to select the area of the image you want to adjust, then press [Enter]. You see the Arc Correction screen. Select Arc Correction and press [Enter]. Press the arrow buttons to adjust the image shape of the selected area as necessary.
Page 59 Image Shape Related Links If you see this screen, you cannot adjust the shape any further in the • "Correcting the Image Shape with Quick Corner" p.54 direction indicated by the gray triangle. • "Correcting Image Shape with Point Correction" p.59 Correcting Image Shape with Point Correction You can use the projector's Point Correction setting to fine-tune the image...
Page 60 Image Shape Select the Installation menu and press [Enter]. Select Point Correction and press [Enter]. Then select Yes and press [Enter] if necessary. Select Point Correction and press [Enter]. Select Geometry Correction and press [Enter]. For fine tuning, select Quick Corner to correct the shape and size of an image roughly, and then select Point Correction to adjust them precisely.
Page 61 Image Shape If you want to change the grid color for visibility, press [Esc], then • To save the current shape of an image you have adjusted, select Save select a different Pattern Color setting in the Point Correction Memory. You can save up to three image shapes in the memory. menu.
Page 62 Resizing the Image with Digital Zoom You can resize the image using the projector's menu. Select the Installation menu and press [Enter]. Turn on the projector and display an image. Press the [Menu] button on the control panel or remote control. Select Digital Zoom and press [Enter].
Page 63 • You cannot use the Epson Setting Assistant app and the Image Shift feature together. If you want to adjust the screen size and position when using the Epson Setting Assistant app, adjust with Quick Corner.
Page 64 Adjusting the Image Position Using Image Shift Use the arrow buttons to adjust the image position. Press the [Esc] button to close the adjustment screen. The adjustment screen disappears if no operation is performed after approximately 10 seconds. The Image Shift setting is retained even if the projector is turned off. You need to re-adjust the position if you change the installation location or angle of the projector.
Page 65 Selecting an Image Source When multiple image sources are connected to the projector, such as a computer and DVD player, you can switch from one image source to the other. Make sure the connected image source you want to use is turned on. For video image sources, insert a DVD or other video media and press play.
Page 66 Image Aspect Ratio The projector can display images in different width-to-height ratios called To cycle through the available aspect ratios for your input signal, press the aspect ratios. Normally, the input signal from your video source determines [Aspect] button repeatedly. the image's aspect ratio.
Page 67 Image Aspect Ratio Aspect mode Description Native Displays images as is (aspect ratio and resolution are maintained). Areas that exceed the edges of the projected screen are not projected.
Page 68 Adjusting Image Quality (Color Mode) The projector offers different color modes to provide optimum brightness, You can also set the Color Mode setting in the projector's Image menu. contrast, and color for a variety of viewing environments and image types. You can select the mode designed to match your image and environment, or experiment with the available modes.
Page 69 Adjusting Image Quality (Color Mode) Press the [Menu] button on the control panel or remote control. Select Dynamic Contrast and press [Enter]. Choose one of the following options and press [Enter]: • Normal for standard brightness adjustment. • High Speed to adjust brightness as soon as the scene changes. Select the Image menu and press [Enter].
Page 70 Setting Frame Interpolation You can use the projector's Frame Interpolation feature to smooth fast-moving Select the Image menu and press [Enter]. video by comparing consecutive image frames and inserting an intermediate image frame between them. Frame Interpolation is available in these conditions: •...
Page 71 Setting Frame Interpolation If your resulting images contain noise, turn off the Frame Interpolation setting.
Page 72 Adjusting the Image Color You can fine-tune various aspects of how colors are displayed in your projected Select the Image menu and press [Enter]. images. Related Links • "Adjusting the Hue, Saturation, and Brightness" p.72 • "Adjusting the Gamma" p.73 Adjusting the Hue, Saturation, and Brightness You can adjust the Hue, Saturation, and Brightness settings for individual image colors.
Page 73 Adjusting the Image Color Do the following as necessary for each setting: Press the [Menu] button on the control panel or remote control. • To adjust the overall hue of the color, bluish - greenish - reddish, adjust the Hue setting. •...
Page 74 Adjusting the Image Color Select and adjust the correction value. Press the left or right arrow buttons to select the color tone you want to adjust on the gamma adjustment graph. Then press the up or down arrow button to adjust the value and press [Enter]. When you select a smaller value, you can reduce the overall brightness of the image to make the image sharper.
Page 75 Adjusting the Image Resolution You can adjust the resolution of the image to reproduce a clear image with an Select the Image menu and press [Enter]. emphatic texture and material feel. Noise Reduction and MPEG Noise Reduction are available when Image Processing is set to Fine.
Page 76 Adjusting the Image Resolution • Noise Reduction Select Image Preset Mode and press [Enter]. • MPEG Noise Reduction • Super-resolution • Auto Contrast Enhancement Adjust each setting in the projector's Image menu individually as necessary. • To reduce flickering in images, adjust the Noise Reduction setting. •...
Page 77 Adjusting the Brightness You can adjust the brightness of your projector's light source. Turning On Automatic Luminance Adjustment You can turn on Dynamic Contrast to automatically optimize the image Turn on the projector and switch to the image source you want to use. luminance.
Page 78 Adjusting the Brightness Select the Image menu and press [Enter]. Press [Menu] or [Esc] to exit the menus. Select Dynamic Contrast and press [Enter]. Choose one of the following options and press [Enter]: • Normal for standard brightness adjustment. • High Speed to adjust brightness as soon as the scene changes.
Page 79 Adjusting Projector Features Follow the instructions in these sections to use your projector's adjustment features. Related Links • "HDMI Link Features" p.80 • "Projecting a PC Free Presentation" p.82 • "Projecting in Content Playback Mode" p.87 • "Shutting Off the Image Temporarily" p.93 •...
Page 80 HDMI Link Features When an audio/video source that meets the HDMI CEC standard is connected • When you use the HDMI Link features, set the HDMI Link setting to to the projector's HDMI port, you can use the projector's remote control to On in the projector's Signal I/O menu.
Page 81 HDMI Link Features Related Links Select the device you want to control and project the image from, and • "Input Signal Settings - Signal I/O Menu" p.122 press [Enter]. • A linked device is indicated by a blue mark. • The device name is left blank if it cannot be acquired. Press [Esc] to select the HDMI Link options as necessary.
Page 82 Projecting a PC Free Presentation You can use your projector's PC Free feature whenever you connect a USB File contents File type Details (extension) device that contains compatible presentation files. This lets you quickly and easily display a presentation and control it using the projector's remote control. Image .jpg Make sure the file is not:...
Page 83 Projecting a PC Free Presentation • When connecting a USB device that includes an AC adapter, connect the AC File contents File type Details (extension) adapter to an electrical outlet when you use the device with your projector. • Some commercially available USB card readers may not be compatible with Movie .mp4/.mov •...
Page 84 Projecting a PC Free Presentation • If the Select Drive screen is displayed, press the arrow buttons to select the drive and press [Enter]. • To display images on the other USB drive, highlight Select Drive at the top of the file list screen and press [Enter]. Do one of the following to locate your files: •...
Page 85 Projecting a PC Free Presentation To play back a movie, press the arrow buttons to highlight the file and You can change the PC Free operation options by highlighting Option at the bottom of the screen and pressing [Enter]. press [Enter]. •...
Page 86 Projecting a PC Free Presentation Setting Options Description Random Transitions between images using a random variety of effects Setting Options Description Display Order Name Order Displays files in name order Date Order Displays files in date order Sort Order In Ascending Sorts files in first-to-last order In Descending Sorts files in last-to-first order...
Page 87 Projecting in Content Playback Mode Your projector's Content Playback feature allows you to project your digital If you set the Content Playback setting to On when the Screen Type signage content. You can easily project playlists that contain images and movies setting is set to a different aspect ratio from the projector's resolution, the saved on an external storage device.
Page 88 See the Epson Projector Content Manager Operation Guide for instructions. • Epson Web Control allows you to create playlists using a Web browser Creating Playlists Using Epson Web Control and save them to an external storage device connected to a projector on a network.
Page 89 Make sure a USB flash drive is connected to the projector's USB-A port. Start your Web browser on your computer or device. Go to the Epson Web Control screen by entering the projector's IP address into the browser's address box. When entering an IPv6 address, wrap the address with [ and ].
Page 90 When you have finished editing the playlist, select Finish. • You can play the playlist from the Remote or Playlist screen. • When you want to specify when the playlist starts and finishes, schedule the playlist using the Epson Projector Content Manager software. Related Links •...
Page 91 • Shape to select the shape effect you want from circles, rectangles, or customized shapes. You can add your images as customized shapes using the Epson Projector Content Manager software. See the Epson Projector Content Manager Operation Guide for details.
Page 92 Projecting in Content Playback Mode Content Playback Mode Restrictions Operating restrictions The following operations cannot be performed in Content Playback mode. • Changing the Color Temp. setting in the Image menu (when Warm White or Cool White is selected as Color Filter) •...
Page 93 Shutting Off the Image Temporarily You can temporarily shut off the projected image and output sound only. Press the [Blank] button on the remote control to temporarily shut off projection. Note that sound is output. To turn the image back on, press the [Blank] button again. Any video action continues to run, however, so you cannot resume projection at the point that you stopped it.
Page 94 Saving Settings to Memory and Using Saved Settings You can save customized settings and then select the saved settings whenever • You can save the following settings: you want to use them. • Image menu settings for each color mode •...
Page 95 Projector Security Features You can secure your projector to deter theft or prevent unintended use by Press the [Menu] button, select the Management menu, and press [Enter]. setting up the following security features: • Button lock security to block operation of the projector using the buttons on the control panel.
Page 96 Projector Security Features Installing a Security Cable You can use the remote control to control the projector even when the buttons on the projector are locked. You can install the security cable on the projector to deter theft. Use the security slot on the projector to attach a Kensington Microsaver •...
Page 97 Projector Security Features Select Web Server Certificate and press [Enter]. • You can use a USB flash drive as an external storage device for this model. Select Register and press [Enter]. • You can also register the digital certificates from your Web browser. However, be sure to register just once or the certificate may not install correctly.
Page 98 Projector Security Features Specification Description Password Up to 64 alphanumeric characters; required...
Page 99 Monitoring and Controlling the Projector Check these sections to monitor and control the projector over a network. Related Links • "Controlling a Networked Projector Using a Web Browser" p.100 • "Registering Digital Certificates from a Web Browser" p.108 • "Using ESC/VP21 Commands " p.109 •...
Page 100 Controlling a Networked Projector Using a Web Browser Once you have connected your projector to your network, you can select Go to the Epson Web Control screen by entering the projector's IP projector settings and control projection using a compatible Web browser. This address into the browser's address box.
Page 101 Select the option corresponding to the projector function you want to control. You may need to log in to access some of the options on the Epson Web Control screen. Set the following passwords first. • To access the Basic Control option, you need to log in using EPSONREMOTE as the user name and your Remote Password.
Page 102 Controlling a Networked Projector Using a Web Browser Returns to the Epson Web Control screen. Turns the projector on. Returns to the Epson Web Control screen. Selects the input source. (The available sources vary depending on your projector Displays the projector's setting menus.
Page 103 Locks/unlocks the projector settings. Turns off test pattern display. Locking prevents accidental changes to the Epson Web Control settings. Updates the projector settings. Advanced The Advanced screen allow you to select the projector's settings.
Page 104 • Display Status • Reset Network Settings • Firmware Update You can select the following settings only with Epson Web Control. • Initial Setting • Monitor Password (up to 16 alphanumeric characters) When performing command communication for the first time, you Returns to the Epson Web Control screen.
Page 105 : Length of the playlist Select the arrow at the bottom-right to display the following screen. Screen displayed while projecting playlist (only in Content Playback mode) Returns to the Epson Web Control screen. Starts projecting the playlist. The icons indicate the playlist settings.
Page 106 USB flash drive or delete the data on the USB flash drive. You can upload .avi, .jpeg (.jpg), .png, .bmp, or .gif files. If you want to add the .mp4 and .mov files to the playlist, use the Epson Projector Content Manager software or the Epson Creative Projection app.
Page 107 Returns to the Epson Web Control screen. Turns the time table on or off. You can specify when each playlist starts and finishes using the time table feature in the Epson Projector Content Manager software. For details, see the Epson Projector Content Manager Operation Guide.
Page 108 Make sure the projector is turned on. Start your Web browser on a computer or device connected to the network. Go to the Epson Web Control screen by entering the projector's IP address Select the certificate file you want to register. into the browser's address box.
Page 109 Using ESC/VP21 Commands You can control the projector from an external device using ESC/VP21. Related Links • "ESC/VP21 Command List" p.109 • "Cable Layouts" p.109 ESC/VP21 Command List When the power ON command is transmitted to the projector, the power turns on and it enters warm-up mode.
Page 110 • Input ports and corresponding input source number Input port name Input source number HDMI1 HDMI2 • Manufacturer name displayed for "Manufacture name information query" EPSON • Model name displayed for "Product name information query" EPSON 815E/810E Related Links • "Getting the Latest Version of the Documents"...
Page 111 Crestron Connected Support If you are using the Crestron Connected network monitoring and control Select the Projector Control menu and press [Enter]. system, you can set up your projector for use on the system. Crestron Connected lets you control and monitor your projector using a Web browser. If you set the Standby Mode setting to Communication On in the projector's Operation menu, you can control the projector even if the projector is in standby mode (when the power is off).
Page 112 Start your Web browser on a computer or device connected to the network. Go to the Epson Web Control screen by entering the projector's IP address into the browser's address box. Select the Crestron Connected settings. See the Crestron Web site for...
Page 113 Web API You can use Web API to operate the projector in Content Playback mode. See Select Projector Control and press [Enter]. the Web API Specifications for Projectors for details. • You can authenticate Web API communications using API authentication (Digest authentication). •...
Page 114 Setting Projector Event Schedules You can schedule up to 30 events to occur automatically on your projector, such Select Add New and press [Enter]. as turning the projector on or off or switching the input source. The projector performs the selected events on the specified date and time in the schedule you set up.
Page 115 Setting Projector Event Schedules Select the event details you want to perform. Select Save and press [Enter]. The scheduled events are displayed on the screen with icons indicating the event status. Select the date and time at which you want the event to occur. : valid schedule : regular schedule : invalid schedule...
Page 116 Setting Projector Event Schedules Select an option from the menu displayed. • On or Off lets you enable or disable the selected event. • Edit lets you change the event details or date and time. • Clear lets you remove the scheduled event from a list. •...
Page 117 Adjusting the Menu Settings Follow the instructions in these sections to access the projector menu system and change projector settings. Related Links • "Using the Projector's Menus" p.118 • "Using the Displayed Keyboard" p.119 • "Image Quality Settings - Image Menu" p.120 •...
Page 118 Using the Projector's Menus You can use the projector's menus to adjust the settings that control how your Press the up or down arrow buttons to move through the menus listed on projector works. The projector displays the menus on the screen. the left.
Page 119 Using the Displayed Keyboard You can use the displayed keyboard to enter numbers and characters. Available Text Using the Displayed Keyboard You can enter the following text when using the displayed keyboard. Use the arrow buttons on the control panel or remote control to highlight the number or character you want to enter and press the [Enter] button.
Page 120 Image Quality Settings - Image Menu Settings on the Image menu let you adjust the quality of your image. The Setting Options Description available settings depend on the currently selected color mode and input source. Sharpness Various levels Adjusts the sharpness or softness of image available details.
Page 121 Image Quality Settings - Image Menu Setting Options Description Setting Options Description Noise Reduction Reduces flickering in images. Gamma -2 to 2 Adjusts the coloring by selecting one of the gamma correction values, or referring This setting is displayed only when Image Custom to a gamma graph.
Page 122 Input Signal Settings - Signal I/O Menu Normally the projector automatically detects and optimizes the input signal Setting Options Description settings. If you need to customize the settings, you can use the Signal I/O menu. Color Space Auto Sets the conversion system for the color The available settings depend on the currently selected input source.
Page 123 Input Signal Settings - Signal I/O Menu Setting Options Description Setting Options Description Image Processing Auto (ALLM) Improves the response speed for images HDMI IN EQ Level HDMI1 Adjusts the HDMI input signal level projected at high speed. depending on the devices connected to Fine HDMI2 the HDMI port.
Page 124 Using Smartphone images using the Epson Setting Assistant app. Fit to Screen Using Corrects the shape and position of images Smartphone to fit on your screen using the Epson Setting Assistant app. Setting Options Description Memory Save customized sets of settings to...
Page 125 Projector Installation Settings - Installation Menu Setting Options Description Setting Options Description Geometry — Guides you step-by-step through Blanking Hides an area of the projected image that Correction Wizard correcting the image shape. you select using the arrow buttons. Bottom Setting is only displayed when Content Digital Zoom Various levels...
Page 126 Projector Display Settings - Display Menu Settings on the Display menu let you customize various projector display Setting Options Description features. Messages Set to On to display messages such as input source name, color mode name, aspect ratio, no signal message, or high temperature warning on your projected image.
Page 127 Projector Feature Settings - Operation Menu Settings on the Operation menu let you customize various projector features. Setting Options Description Light Source Light Source Mode Select the brightness for the light source. Brightness Control • Normal: maximum brightness. • Medium: 75% brightness. •...
Page 128 Projector Feature Settings - Operation Menu Setting Options Description Setting Options Description Standby Mode Communication Set to Communication On to allow Indicators Set to Off to turn off the indicator lights monitoring and controlling the projector on the projector except when an error or over a network when the projector is in warning occurs.
Page 129 Projector Administration Settings - Management Menu Settings on the Management menu let you customize various projector Setting Options Description administrative features. Control Panel Lock Full Lock Controls projector button locking to secure the projector: Except for Power • Full Lock: locks all buttons. •...
Page 130 Projector Administration Settings - Management Menu Setting Options Description Setting Options Description Date & Time Date & Time Adjusts the projector's system time and Reset Management — Resets all adjustment values on the date settings. Select Daylight Saving Settings Management menu to their default Daylight Saving Time to set daylight saving time settings settings, except for Language.
Page 131 Projector Network Settings - Network Menu Related Links Settings on the Network menu let you view network information and set up the • "Network Menu - Network Settings Menu" p.131 projector for controlling over a network. Network Menu - Network Settings Menu Settings on the Network Settings menu let you select the basic network settings.
Page 132 IPv6. projectors with a switcher and a system IPv6 is supported to monitor and control controller. the projector over a network using Epson Web Control and PJLink. Web API Settings Web API Select On to enable the Web API...
Page 133 AMX Device Set to On to monitor and control the Basic Control Discovery projector to be detected by AMX Device projector using Basic Control in Epson Discovery. Web Control. Crestron Set to On only when monitoring or This setting is only displayed when...
Page 134 Image Quality Memory Settings - Memory Menu Settings on the Memory menu let you manage saving and loading of image quality settings in the projector's memory. Setting Options Description Save Memory Memory 1 to 10 Saves customized sets of settings to memory.
Page 135 Projector Setup Settings - ECO Menu Settings on the ECO menu let you customize projector functions to save power. Setting Options Description Light Source Mode — See the Operation menu table for details on the Light Source Mode settings. Sleep Mode —...
Page 136 Projector Initial Settings and Reset Options - Initial/All Settings Menu Reset All options Settings on the Initial/All Settings menu let you reset certain projector settings to their default values and place the projector in firmware update mode so you When you select Reset All, you see the following screen. can update the firmware.
Page 137 The indicators start flashing and the batch setup file is written to the USB Caution flash drive. When writing is finished, the projector turns off. Epson takes no responsibility for batch setup failures and associated repair costs due to power outages, communication errors, or other problems that may cause such Caution failures.
Page 138 Copying Menu Settings Between Projectors (Batch Setup) Transferring Settings From a Computer Remove the USB flash drive. You can copy menu settings from one projector to another of the same model by The file name for the batch setup file is PJCONFDATA.bin. If you connecting the computer and projector with a USB cable.
Page 139 Copying Menu Settings Between Projectors (Batch Setup) Eject the USB device (Windows) or drag the removable disk icon to the Caution Trash (Mac). Do not disconnect the power cord from the projector while the file is being written. If the power cord is disconnected, the projector may not start Disconnect the USB cable.
Page 140 Maintaining the Projector Follow the instructions in these sections to maintain your projector. Related Links • "Projector Maintenance" p.141 • "Cleaning the Projection Window" p.142 • "Cleaning the Obstacle Sensor" p.143 • "Cleaning the Projector Case" p.144 • "Air Filter and Vent Maintenance" p.145 •...
Page 141 The only parts you should replace are the air filter and remote control batteries. If any other part needs replacing, contact Epson or an authorized Epson servicer. Warning Before cleaning any part of the projector, turn it off and unplug the power cord.
Page 142 Cleaning the Projection Window Clean the projection window periodically, or whenever you notice dust or smudges on the surface. • To remove dust or smudges, gently wipe the projection window with clean and dry lens-cleaning paper. • If the projection window is dusty, blow off dust using a blower, and then wipe the projection window.
Page 143 Cleaning the Obstacle Sensor Clean the projector's obstacle sensor glass periodically, or if you see a message telling you to remove any obstacles that are interfering with the projection area. To remove dust or smudges, gently wipe the sensors with lens-cleaning paper. Warning Do not use a lens cleaner that contains flammable gas to clean the obstacle sensor.
Page 144 Cleaning the Projector Case Before cleaning the projector case, turn off the projector and unplug the power cord. • To remove dust or dirt, use a soft, dry, lint-free cloth. • To remove stubborn dirt, use a soft cloth moistened with water and mild soap.
Page 145 0.04 to 0.2 mg/m3.) Attention If regular maintenance is not performed, your Epson projector will notify you when the temperature inside the projector has reached a high level. Do not wait until this warning appears to maintain your projector filter as prolonged exposure to high temperatures may reduce the life of your projector.
Page 146 Air Filter and Vent Maintenance Slide the air filter cover latch and pull out the air filter cover. Attention • Do not rinse the air filter in water, or use any detergent or solvent to clean • Do not use canned air. The gases may leave a flammable residue or push dust and debris into the projector's optics or other sensitive areas.
Page 147 Air Filter and Vent Maintenance Replace the front cover. Carefully remove the front cover fixing points on the left and right side of the cover. Replacing the Air Filter You need to replace the air filter in the following situations: •...
Page 148 Air Filter and Vent Maintenance Slide the air filter cover latch and pull out the air filter cover. Place the new air filter with the four tabs facing down as shown. Attention Do not force the air filter cover to close with the tabs on the air filter facing up. Pull the air filter out of the projector.
Page 149 Air Filter and Vent Maintenance Cleaning the Air Intake Vents Clean the projector's air intake vents periodically, or whenever you notice dust on the surface of the vents to prevent the projector from overheating due to blocked ventilation. Turn off the projector and unplug the power cord. Turn the projector upside down.
Page 150 Adjusting the Color Convergence (Panel Alignment) You can use the Panel Alignment feature to manually adjust the color Select Panel Alignment and set it to On. convergence (the alignment of the red and blue colors) in the projected image. You can adjust the pixels horizontally and vertically in increments of 0.125 pixels within a range of ±...
Page 151 Adjusting the Color Convergence (Panel Alignment) Select one of the following options: • Select Shift the whole panel to adjust the entire panel at the same time and go to the next step. • Select Adjust the four corners to adjust the corners of the panel one at a time and go to step 10.
Page 152 Download the projector firmware file from the Epson Web site. Copy the downloaded firmware file to the root folder (highest folder in the hierarchy) of the USB storage device.
Page 153 • macOS 10.13.x or later All of the projector's indicators start flashing and the firmware update Download the projector firmware file from the Epson Web site. starts. When the update finishes normally, the projector enters standby status (only the power indicator is lit blue). If Direct Power On is set to On in the projector's Operation menu, the projector turns back on again.
Page 154 Do not disconnect the power cord from the projector while the contact Epson. firmware is updating. If the power cord is disconnected, the • If no operations are performed for 20 minutes in update mode, the projector may not start correctly.
Page 155 Solving Problems Check the solutions in these sections if you have any problems using the projector. Related Links • "Projection Problems" p.156 • "Projector Indicator Status" p.157 • "Solving Image or Sound Problems" p.159 • "Solving Projector or Remote Control Operation Problems" p.165 •...
Page 156 If this does not solve the problem, check the following: • The indicators on the projector may indicate the problem. • The solutions in this manual can help you solve many problems. If none of these solutions help, contact Epson for technical support.
Page 157 Flashing orange Laser has a problem. Turn the projector off, unplug it, and contact Epson for help. A fan or sensor has a problem. Turn the projector off, unplug it, and contact Epson for help.
Page 158 • Make sure that the vents and air filter are not clogged with dust or obstructed by nearby objects. • Clean or replace the air filter. • If the problem persists, unplug the projector and contact Epson for help. Related Links • "Projector Administration Settings - Management Menu" p.129 •...
Page 159 Contact • "Solutions When the Image Brightness or Colors are Incorrect" p.163 Epson for help. • "Solutions When an Afterimage Remains on the Projected Image" p.163 • "Solutions to Sound Problems"...
Page 160 Solving Image or Sound Problems Solutions When "No Signal" Message Appears If the same image is not displayed by the laptop and projector, check the Windows Display utility to make sure the external monitor port is If the No Signal message appears, try the following solutions: enabled and extended desktop mode is disabled.
Page 161 Solving Image or Sound Problems • If you are projecting from an HDMI source, change the HDMI IN EQ Level • Make sure you selected the correct Projection setting in the projector's setting in the projector's Signal I/O menu. After changing the setting, you Installation menu.
Page 162 Solving Image or Sound Problems • "Input Signal Settings - Signal I/O Menu" p.122 Solutions When the Image Contains Noise or Static If the projected image contains electronic interference (noise) or static, try the Solutions When the Image is Fuzzy or Blurry following solutions: •...
Page 163 Solving Image or Sound Problems Related Links Solutions When the Image Brightness or Colors are • "Projector Administration Settings - Management Menu" p.129 Incorrect If the projected image is too dark or light, or the colors are incorrect, try the Solutions to Sound Problems following solutions: If there is no sound or the volume is too low or high, try the following solutions:...
Page 164 Solving Image or Sound Problems Solutions When Image File Names are not Displayed Correctly in PC Free If any file names are longer than the display area or include unsupported symbols, the file names are shortened or changed in PC Free. Shorten or change the file name.
Page 165 Solving Projector or Remote Control Operation Problems • The power cord may be defective. Disconnect the cord and contact Epson for Check the solutions in these sections if you have problems operating the help. projector or remote control. Related Links Related Links •...
Page 166 • If you have entered an incorrect password too many times and see a message displaying a request code, write down the code and contact Epson for help. Provide the request code and proof of ownership for assistance in unlocking the projector.
Page 167 Solutions to Problems in Content Playback Mode If you cannot play back a playlist correctly, try the following solutions: • Make sure Content Playback is set to On. Operation > Content Playback • Make sure the USB flash drive contains a playlist. •...
Page 168 • For the infrastructure mode, make sure you have access to the network the projector is on. • If your Web browser is set up to connect via a proxy server, the Epson Web Control screen cannot be displayed. Make settings for a connection without using a proxy server.
Page 169 Solutions When HDMI Link does not Function If you cannot operate the connected devices using the HDMI Link features, try the following solutions: • Make sure the cable meets the HDMI CEC standard. • Check if the device is available in the Device Connections list. If the device does not appear in the Device Connections list, it does not meet the HDMI CEC standards.
Page 170 • "Supported Monitor Display Resolutions" p.174 • "Projector Specifications" p.175 • "External Dimensions" p.176 • "Supported Features for Epson Projector Content Manager" p.177 • "List of Safety Symbols and Instructions" p.178 • "Laser Safety Information" p.180 • "Glossary" p.183 •...
Page 171 October 2024. Special expertise is required to suspend the projector from a ceiling. Details of accessories are subject to change without notice and availability may Contact Epson for help. vary depending on the country of purchase. Related Links • "Screens"...
Page 172 Screen Size and Projection Distance Check the table here to determine how far to place the projector from the screen 16:9 screen size based on the size of the projected image. Wide 160" 354 × 199 57.8 32.2 27.1 226.4 4:3 screen size Wide 66"...
Page 173 Screen Size and Projection Distance 16:6 screen size Wide 75" 178 × 67 27.6 94.5 80" 190 × 71 29.9 101.2 90" 214 × 80 34.1 34.3 114.5 100" 238 × 89 38.1 12.6 38.7 127.9 110" 262 × 98 42.1 16.6 43.1...
Page 174 Supported Monitor Display Resolutions See the Specifications for detailed information on compatible refresh rates and resolutions for each compatible video display format.
Page 175 Projector Specifications Mass Approx. 12.0 kg Product name EH-QS100B/EH-QS100W * Pixel shifting technology achieves 4K resolution on screen. Dimensions 695 (W) × 145 (H) × 341 (D) mm (not including raised section) ** Approximate time until the light source brightness decreases to half of its original value.
Page 176 External Dimensions Center of the projection window The unit in these illustrations is mm.
Page 177 Supported Features for Epson Projector Content Manager Your projector supports the following features and options of the Epson Projector Content Manager software. Features/Options EH-QS100B/EH-QS100W Simultaneous playback Save the playlist to the projector via a network ✓ Settings > Video Format Auto Select ✓...
Page 178 List of Safety Symbols and Instructions The following table lists the meaning of the safety symbols labeled on the Symbol mark Approved Description standards equipment. IEC60417 Polarity of d.c. power connector Symbol mark Approved Description No. 5926 To identify the positive and negative standards connections (the polarity) on a piece of equipment to which a d.c.
Page 179 List of Safety Symbols and Instructions Symbol mark Approved Description Symbol mark Approved Description standards standards IEC60417 Alternating current ISO 3864 Disassembly prohibition No. 5032 To indicate on the rating plate that the To indicate a risk of injury, such as equipment is suitable for alternating electric shock, if the equipment is current only;...
Page 180 Laser Safety Information Inside This projector is a Class 1 laser product that complies with the IEC60825-1:2014 and EN60825-1:2014 + A11:2021international standards for lasers. Follow these safety instructions when using the projector. Warning • Do not open the projector's case. The projector contains a high-powered laser. •...
Page 181 • Do not allow small children to operate the projector. Children must be Rating Labels (EH-QS100W, EH-QS100B) accompanied by an adult. • Do not look into the lens during projection. Also, do not look into the lens using The rating label contains the certification and identification information for the optical devices, such as a magnifying glass or telescope.
Page 182 Laser Safety Information...
Page 183 It also provides an encryption function for the digital signal. Epson have implemented this protocol technology, and have provided a setting to enable the protocol function (ON). HDTV An abbreviation for High-Definition Television that refers to See the AMX Web site for more details.
Page 184 Glossary sRGB An international standard for color intervals that was formulated so that colors that are reproduced by video equipment can be handled easily by computer operating systems (OS) and the Internet. If the connected source has an sRGB mode, set both the projector and the connected signal source to sRGB.
Page 185 However, there is no We: Epson America, Inc. guarantee that interference will not occur in a particular installation. If this Located at: 3131 Katella Avenue, Los Alamitos, CA...
Page 186 It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than Manufacturer: SEIKO EPSON CORPORATION one interface connector, do not leave cables connected to unused interfaces.
Page 187 Trademarks Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident, misuse, or abuse of this EPSON is a registered trademark of Seiko Epson Corporation.
Page 188 Notices 2024.10 414546500EN...
