xiv Preface
Appendix A — Connector Pin Assignments provides a list of system, riser, and option
board internal connector pin assignments and a list of external pin assignments for the
keyboard, mouse, serial ports, parallel port, network ports, and video port.
Appendix B —Jumper Settings provides jumper settings for the system board, and for
options that may ship with the computer, including the CD-ROM reader and the fax/modem
board.
NOTE: The PowerMate NetPC system is
designed to be repaired by qualified, NECCSD-
trained technicians at the depot level of service.
