C
ONFIGURING THE
Parameter
64 Bytes Frames
65-127 Byte Frames
128-255 Byte Frames
256-511 Byte Frames
512-1023 Byte Frames
1024-1518 Byte Frames
1519-1536 Byte Frames
Web – Click Port, Port Statistics. Select the required interface, and click
Query. You can also use the Refresh button at the bottom of the page to
update the screen.
3-106
S
WITCH
Table 3-9. Port Statistics
Description
The total number of frames (including bad packets)
received and transmitted that were 64 octets in length
(excluding framing bits but including FCS octets).
The total number of frames (including bad packets)
received and transmitted where the number of octets
fall within the specified range (excluding framing bits
but including FCS octets).

Figure 3-49. Displaying Port Statistics
