C L
OMMAND INE
Example
Console#show ip access-group
Interface ethernet 1/25
IP standard access-list david
Console#
Related Commands
ip access-group (4-119)

map access-list ip

This command sets the output queue for packets matching an ACL rule.
The specified CoS value is only used to map the matching packet to an
output queue; it is not written to the packet itself. Use the no form to
remove the CoS mapping.
Syntax
[no] map access-list ip acl_name cos cos-value
• acl_name – Name of the ACL. (Maximum length: 16 characters)
• cos-value – CoS value. (Range: 0-7)
Default Setting
None
Command Mode
Interface Configuration (Ethernet)
Command Usage
• You must configure an ACL mask before you can map CoS values to
the rule.
• A packet matching a rule within the specified ACL is mapped to one
of the output queues as shown in the following table. For information
on mapping the CoS values to output queues, see queue cos-map on
4-213.
Priority
Queue
4-120
I
NTERFACE

Table 4-35 Egress Queue Priority Mapping

0 1
1 2
2 3 4
0 3 4
5 6 7
5 6 7
