TigerSwitch
8608SX
SMC's Tiger Line of feature rich work-group LAN solutions
SMC's new TigerSwitch™ 1000 is a Gigabit Ethernet backbone switch that provides 8 full-duplex 1000BASE-SX (SC-type) ports. With 16 Gbps of bandwidth,
this switch dramatically improves the performance of congested networks. A host of advanced features and comprehensive management capabilities make
this device a potent solution for the network core.
The TigerSwitch 1000 provides high bandwidth and high-performance connectivity between workgroups with increased capacity for server farms, users have
faster access to network-wide resources. Moreover, the 1000BASE-SX (SC-type) fibre optic ports support connections up to 550 meters (1800 feet) in length.
This TigerSwitch 1000 also comes fully-loaded with advanced performance-enhancing features. IGMP maintains available bandwidth by limiting multicast
transmissions to subscribers only. Broadcast storm suppression prevents broadcast traffic storms from engulfing the network. QoS priority queueing ensures the
minimum delay for real-time multimedia data across the network. Flow control eliminates the loss of packets due to bottlenecks caused by port saturation.
Port-based and tagged VLANs are also included to provide traffic security and efficient use of network bandwidth.
The TigerSwitch 1000's integrated SNMP management agent supports 4-group RMON with in-band and out-of-band connection options. Additionally, the
Web-based interface means that the TigerSwitch can be managed at any time from anywhere, removing the limitations and costs associated with a fixed
management station.
Features and Benefits
Outstanding Performance
8 full-duplex 1000BASE-SX ports
16 Gbps of aggregate bandwidth
QoS support with two priority queues and
Weighted Fair Queueing
IGMP filtering and snooping provides complete control
of multicast packets
Broadcast storm suppression prevents broadcast
traffic storms from engulfing the network
Address table of up to 12K MAC addresses
Full-duplex flow control eliminates lost packets
due to port saturation
Flexible
Up to 16 IEEE 802.1Q VLANs provide maximum security
and bandwidth efficiency
Port mirroring allows detailed analysis of traffic crossing
any port in real time
Rack-mountable (standard 19" rack)
Supports a redundant power supply for fail-safe operation
TM
1000
Manageable
In-band via Telnet, or any SNMP-based
management application
Out-of-band via RS-232 console port
Web management agent for switch configuration
access anytime, anywhere
4-group RMON (groups 1, 2, 3, 9)
Spanning Tree Protocol allows the creation of
redundant data paths
Compatible
IEEE 802.3z, 802.3x, 802.1D, 802.1Q, and 802.1p
Reliable
Three year warranty
Free pre and post purchase technical support
Web Site
http://www.smc-europe.com
