C
ONFIGURING THE
Web – Click Port, LACP, Port Internal Information. Select a port channel
to display the corresponding information.
CLI – The following example displays the LACP configuration settings
and operational state for the local side of port channel 1.
Console#show 1 lacp internal
Channel group : 1
-------------------------------------------------------------------
Oper Key : 4
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------
LACPDUs Internal : 30 sec
LACP System Priority : 32768
LACP Port Priority : 32768
Admin Key : 4
Oper Key : 4
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State : distributing, collecting, synchronization,
aggregation,
. .
.
Console#
3-94
S
WITCH

Figure 3-44. Displaying LACP Port Information

long timeout, LACP-activity
4-158
