C
ONFIGURING THE
Priority Level
1
2
0 (default)
3
4
5
6
7
Command Attributes
• Priority – CoS value. (Range: 0-7, where 7 is the highest priority)
• Traffic Class* – Output queue buffer. (Range: 0-7, where 7 is the
highest CoS priority queue)
* CLI shows Queue ID.
Web – Click Priority, Traffic Classes. Mark an interface and click Select to
display the current mapping of CoS values to output queues. Assign
priorities to the traffic classes (i.e., output queues) for the selected
interface, then click Apply.

Figure 3-71. Configuring Ports and Trunks for Class of Service

3-156
S
WITCH

Table 3-11. CoS Priority Levels

Traffic Type
Background
(Spare)
Best Effort
Excellent Effort
Controlled Load
Video, less than 100 milliseconds latency and jitter
Voice, less than 10 milliseconds latency and jitter
Network Control
