Command Attributes
• Trap Manager Capability – This switch supports up to five trap
managers.
• Current – Displays a list of the trap managers currently configured.
• Trap Manager IP Address – Internet address of the host (the
targeted recipient).
• Trap Manager Community String – Community string sent with the
notification operation. (Range: 1-32 characters, case sensitive)
• Trap Version – Specifies whether to send notifications as SNMP v1
or v2c traps. (The default is version 1.)
• Enable Authentication Traps – Issues a trap message whenever an
invalid community string is submitted during the SNMP access
authentication process. (The default is enabled.)
• Enable Link-up and Link-down Traps – Issues link-up or
link-down traps. (The default is enabled.)
Web – Click SNMP, Configuration. Fill in the IP address and community
string for each trap manager that will receive trap messages, and then click
Add. Select the trap types required using the check boxes for
Authentication and Link-up/down traps, and then click Apply.

Figure 3-22. Configuring IP Trap Managers

CLI – This example adds a trap manager and enables both authentication
and link-up, link-down traps.
Console(config)#snmp-server host 192.168.1.19 private version 2c
4-127
Console(config)#snmp-server enable traps
S N
IMPLE ETWORK
M
ANAGEMENT
P
ROTOCOL
4-129
3-41
