c. Run #22-12 AWG wire through the outdoor rated conduit fitting and wire the control signals to
the terminal blocks (24) as shown in
Figure 2-18 Running AWG wire to the terminal blocks
24 Terminal blocks
d. Refer to Appendix-A: Fan Control Wiring Diagram, page 35
inclusion of a HOA switch.
e. Place the warning decal as shown in
wiring connected to them.
Figure 2-19 Fan control warning decal
PNEG-2394 Fan Control Module
Chapter 2: Installing the Fan Control Module
Figure 2-18, page 27.
for proper fan control wiring with the
Figure 2-19, page 27 onto all fans with GrainVue fan control
