2. Replace the removed knockout plug with an outdoor rated conduit fitting.
Figure 2-11 Replacing knockout plug with outdoor rated conduit fitting
1
Fan Control Module
3. Run the outdoor rated #14-12 AWG cable through the conduit fitting to the DIN rail components at
connection points as shown in
minimum, and is rated for operation from -40°C to 50°C (-40°F to 122°F).
4. Connect the outdoor rated cable to a circuit protected by a 250V, 15A circuit breaker. Label the
circuit breaker to indicate that it is used to control power to the GrainVue Fan Control Module, and
make sure that the ON and OFF positions are clearly identified.
PNEG-2394 Fan Control Module
Chapter 2: Installing the Fan Control Module
21
Figure 2-11, page
23. Make sure the cable is rated for 300 VAC
Power cable
23
