Take The Feed Kitchen Out Of Operation In The Filling Mode; Put The Feed Kitchen In The Filling Mode With The Console - LELY Vector Operator's Manual

2. Connect the Mixing and Feeding Robot manually to the charger:
1. Go to the page Work.
Tab Work
Information about the
current state
2. Manually drive (see Drive the Mixing and Feeding Robot Manually on page 5-34) the Mixing and
Feeding Robot close to the charger and make sure the Feeding Robot is on the strip with the
charger plug toward the charger.
1. When the following message appears on your display: SAFETY WARNING Manual operation is
permitted only with a clear overview of the vehicle. Confirm?
2. Confirm if you have a clear overview of the Mixing and Feeding Robot.
3. Push the button
4. Push to start driving slowly to the charger, the Feeding Robot will stop when a resistance is
detected and connect to the charger.
3. Go to the page Work on the first tab.
4. Push the button
Start the Mixing and Feeding Robot when it was out of operation (Off).
•
5.1.3

Take the Feed Kitchen Out of Operation in the Filling Mode

5.1.3.1

Put the Feed Kitchen in the Filling Mode with the Console

1. On the console, push the start button (1) (see figure 36 on page 5-2).
The signal lights start blinking green and orange. The Feed Grabber will be parked.
2. Wait until the signal light is blinking green. It is then safe to enter and fill the feed kitchen.
Operating Instructions
Tab Work
information
Information about the
feed or scan task
(one or more times) to go to the tab MANUAL CHARGER.
to:
Tab MANUAL
DRIVING
Buttons for manual
driving
in n o vato rs in ag ric u ltu re
Tab MANUAL
CHARGER
Drive and connect to
the charger
5-3
