Reset The Feed Grabber; Reinstall The Chain After Activation Of The Safety Handle - LELY Vector Operator's Manual

7.9

Reset the Feed Grabber

1. Take the Feed Kitchen out of Operation (see Put the Feed Kitchen in the Filling Mode with the Console
on page 5-3).
2. Wait a few seconds.
3. Put the feed kitchen in operation (see Put the Feed Kitchen in Operation on page 5-1).
7.10

Reinstall the Chain After Activation of the Safety Handle

Preparation
1. Connect the smartphone to the Mixing and Feeding Robot.
2. Manually drive the Mixing and Feeding Robot away from the feed loading point.
3. Push the pause button and switch off the Mixing and Feeding Robot with the key (see procedure).
4. If there are 2 Mixing and Feeding Robots, push the pause button on the second Mixing and Feeding
Robot and switch off the Mixing and Feeding Robot with the key.
Position the Feed Grabber
1. Take the Feed Grabber out of operation (see procedure).
A no go zone is an area in the feed kitchen with a wall or equipment over which the Feed
Grabber must never drive. If there is a no go zone in your feed kitchen, first drive the
feed Grabber away from the no go zone before you drive the Bridge Crane.
2. If there is a Bridge Crane present:
1. Connect the smartphone to the Bridge Crane.
2. Take the Bridge Crane out of operation (see procedure).
3. Go to the page Manual operation > Driving.
4. Drive the Bridge Crane to the Y position of the feed loading point.
3. Connect the smartphone to the Feed Grabber.
4. Go to the page Testing > Test Drive Motor.
5. Use the buttons
point.
Use the button
7-22
BACKWARD or FORWARD to drive the Feed Grabber to the feed loading
to go to the previous menu.
in n o vato rs in ag ric u ltu re
Troubleshooting
