Remove the feed
Sharp knives.
Risk of severe injury
Never climb into the mixing bin when it is filled with feed because the knives can cause
severe cuts.
1. Switch off the Mixing and Feeding Robot with the key (see Switch off the Mixing and Feeding Robot
with the Key (MFR 2) on page 5-10).
2. Use the Vector stepladder and remove the feed from the mixing bin with a pitchfork.
3. Switch on the Mixing and Feeding Robot with the key (see Switch on the Mixing and Feeding Robot
with the Key on page 5-14).
7.5

Release a Jammed Dosing Roll

Do this procedure when the dosing roll is jammed because there is too much feed with long fibers around
the dosing roll.
Turn the dosing roll in the opposite direction
1. Connect the smartphone (see Connect the Smartphone to Device Software on page 5-15) to the Mixing
and Feeding Robot.
2. Use the password you received from your Lely technician and:
Select the page Test> Test motors > Dosing roller.
3. Push .
4. Push a few seconds until the dosing roll is turning.
5. Push .
6. Push a few seconds until the dosing roll is turning smoothly,
if the dosing roll does not turn:
1. Clean the dosing roll (see Clean the Dosing Roll and Position Sensor on page 6-3).
7.6

Release a Jammed Feed Door

Do this procedure when the feed door is jammed because feed is stuck.
1. Connect the smartphone (see Connect the Smartphone to Device Software on page 5-15) to the Mixing
and Feeding Robot.
2. Select the page Test> Test motors > Feed door motor.
3. Push button
4. Switch off the Mixing and Feeding Robot with the key (see Switch off the Mixing and Feeding Robot
with the Key (MFR 2) on page 5-10).
Troubleshooting
to open the door.
