O P E R A T O R ' S M A N U A L
SPLENDIMO TC
SPLENDIMO 280 TC
E-HV.008.
0202

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPLENDIMO TC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LELY SPLENDIMO TC

  • Page 1 O P E R A T O R ’ S M A N U A L SPLENDIMO TC SPLENDIMO 280 TC E-HV.008. 0202...
  • Page 3 SPLENDIMO TC Ehe008 ® SPLENDIMO is a registered trademark. The right of exclusive use belongs to the companies of the Lely organisation. ©2002. All rights reserved. Nothing of this publication may be reproduced and/or published by printing, photocopying, microfilm or any...
  • Page 5: Table Of Contents

    TABLE OF CONTENTS ....................page PREFACE ..........................29 WARRANTY CONDITIONS .....................29 TYP- AND SERIAL NUMBER OF YOUR MACHINE ............29 SAFETY INSTRUCTIONS ....................30 EXPLANATION OF SAFETY DECALS ON THE MACHINE ........31 1 INTRODUCTION ......................32 2 MOUNTING BEHIND THE TRACTOR ..............33 3 TRANSPORT .......................34 4 MACHINE ADJUSTMENTS ..................34 Mowing height....................34 Intensity of conditioning ...................35...
  • Page 7: Preface

    PREFACE This manual is meant for personnel that are operating the machine and are responsible for its daily maintenance. Kindly read this manual fully prior to starting work. Such instructions as are related to your safety and/or that of others are marked in the margin by a warning triangle with exclamation mark.
  • Page 8: Safety Instructions

    - Observe the prevailing legislation for public road transport - Use flashing lights or other safety signs, when required. - Don’t stand on the machine. - Use genuine LELY parts only. - Remove the pressure from hydraulic systems before star- ting work on them and/or before coupling/uncoupling hydraulic hoses.
  • Page 9: Explanation Of Safety Decals On The Machine

    EXPLANATION OF SAFETY DECALS ON THE MACHINE • Carefully read operator’s manual before handling the machine. Observe instructions and safety rules when operating. • Attention! Moving parts. Stay clear of rotating machine parts. • Danger of flying objects. Maintain a sufficient, safe distance from the machine as long as the tractor engine is running.
  • Page 10: Introduction

    Cutting units rotate either to the left or right. Standard configurations are shown in fig. 2. If required, the cutting units of the SPLENDIMO TC mower with “S” model discs can be fitted in a different configuration (depending upon the combination of disc/ knife).
  • Page 11: Mounting Behind The Tractor

    2 MOUNTING BEHIND THE TRACTOR The headstock is fitted with double linkage pins (category II) giving two linkage possibilities (fig. 3) and allowing adjust- ment of the offset position of the machine behind the tractor. - Choose position  for the SPLENDIMO 240 TC mower and position ‚...
  • Page 12: Transport

    3 TRANSPORT The SPLENDIMO TC mower can be transported on the tractor’s 3-point hitch. - Pull up the locking hook for the hydraulic ram and retract the ram completely. - Check if the ram is secured by the locking hook (fig. 5).
  • Page 13: Intensity Of Conditioning

    Intensity of conditioning The intensity of conditioning can be adjusted by means of the conditioner’s crop inlet plate and through the rotor speed. - Adjust the crop inlet plate. Position (A, fig. 7) ensures the highest intensity of conditioning, whereas it is lowest when the crop inlet plate is adjusted to the (B) position.
  • Page 14: Operating The Machine

    For total folding of the machine, the locking hook needs to be pulled up. Mind the following directions when working with the SPLENDIMO TC mower. - Lower the machine by means of the hydraulic ram until it is just above crop level.
  • Page 15 Should the machine hit an obstacle during mowing, it can move backward thanks to the extension of the breakback device (fig. 13). - After extension of the breakback device: drive backwards a few meters until the breakback device has locked back into position.
  • Page 16: Dismounting From The Tractor

    6 DISMOUNTING FROM THE TRACTOR - Lower the machine. - Switch off the tractor engine. Disengage the PTO shaft from the tractor PTO. - Place the PTO shaft in the hook (fig. 15). - Set the parking jack in the lowest position. - Lower the three point hitch until the parking jack is supported by the ground.
  • Page 17: Maintenance

    7 MAINTENANCE Correct machine servicing is necessary with a view to reliable and safe working. Maintenance after operations - Clean the machine thoroughly. After jet-cleaning allow for a few moments rotation of the discs so that the water is swept away. - Check the mower knives and discs for tightness and damage (see §...
  • Page 18: Intermittent Maintenance

    Intermittent maintenance Intermittent maintenance has to be carried out: • At the start of the haymaking season; • Before prolonged storage of the machine; • When the machine is used extensively during the season. - Grease the PTO shafts. - Grease the profiled tubes of the PTO shaft. - Grease the spring-loaded locking pins of the yoke lock of the PTO shaft.
  • Page 19 - Check all bolts and nuts for tightness. Pay particular attention to the bolts which secure the skids and wear plates (fig. 23). When tightening loose bolts/nuts the torques listed below should be applied. M10 M12 M14 M16 M20 M24 135 215 410 710 13,5...
  • Page 20: Replacement Of Knives

    Replacement of knives The mower knives come in 2 different versions for discs with LH or RH rotation. The front of the cutting edge has to point downward, viewed in the direction of rotation of the disc (fig. 50-60 Nm 25).
  • Page 21: Change Of Grease In Mower Elements

    - Fill the gearbox D (fig. 28) with 0.8 l transmission oil (GP80W90). Change of grease in mower elements Replace the grease in the mower elements every 500 working 36 Nm (3,6 kgm) hours or every 1,000 hectares. Follow the directions listed hereafter. - Remove the mower disc.
  • Page 22: Acutter Bar Assembly/Disassembly

    Supplement A A CUTTER BAR ASSEMBLY/DISASSEMBLY The figures placed between brackets correspond with the numerals in figure A-1. The cutter bar is built up of independent units (1). These mower elements are kept apart by intermediate spacers (2). The units and spacers are kept together by a connecting rod (3).
  • Page 23 - Fit the elements in the standard configuration of directions of rotation (fig. A-3) or in a configuration at your choice. ® • A RH rotation SPLENDIMO TC mower element can be SPLENDIMO 240 TCN identified as follows.
  • Page 24 Supplement A - Tighten the nut (7). Torque: 950 Nm (95 kgm). This torque is realised by extending your wrench with a 150 cm long pipe (fig. A-5) and by then applying a force of 635 N 635 N (63,5 kg). 63.5 kg When fitting the securing plate the nut should be tightened and is not allowed to be unscrewed.
  • Page 25: Btechnical Details

    Supplement B B TECHNICAL DETAILS ® SPLENDIMO 240 TC 280 TC Working width 2,40 m 2,80 m Transport width 1,95 m 1,95 m Weight approx. 750 kg 825 kg Power required 40 kW 44 kW (55 HP) (60 HP) PTO output 540 r.p.m.
