Take The Feed Grabber Out Of Operation; Put The Bridge Crane In Operation - LELY Vector Operator's Manual

2. Select the page Operation,
The page displays the current status.
3. Push the button
4. If you want to go on with the present task, select Resume Operation and push the button
It may be necessary to let the Mixing and Feeding Robot send the task to grab again if the Feed
Grabber had accepted the task when it went out of operation.
To make the Mixing and Feeding Robot resend the task:
1. Connect the smartphone to the Mixing and Feeding Robot.
2. Take the Mixing and Feeding Robot out of operation using the smartphone (see Take the Mixing
and Feeding Robot Out of Operation on page 5-4).
3. Put the Mixing and Feeding Robot in operation and select Yes, to resume the task.
The Feed Grabber will receive the task once more and resume operation.
5. If you want to restart the program, select Restart Operation and push the button
If the Feed Grabber is powered On, for example after a power failure, it automatically
drives until it detects the main reset point. When the Feed Grabber detected the main
reset point it is automatically set to In operation.
5.1.5.3

Take the Feed Grabber Out of Operation

1. Connect the smartphone (see Connect the Smartphone to Device Software on page 5-15) to the Feed
Grabber.
2. Select the page Operation,
The page displays the current status.
3. Push the button
4. If you want to stop operation immediately, select Stop Immediately and push the button
5. If you want to stop operation after the current task is finished, select Stop After Task and push the
button .
5.1.5.4

Put the Bridge Crane In Operation

When the Bridge Crane starts after the power is put on the Vector system it
automatically goes in operation.
Operating Instructions
.
.
in n o vato rs in ag ric u ltu re
.
.
.
5-7
