1. Connect the smartphone (see Connect the Smartphone to Device Software on page 5-15) to the Bridge
Crane.
2. Select the page Put in operation
The page displays the current status.
3. Push the button
The Bridge Crane will automatically drive to detect the reset magnets after it receives
the first task from the Feed Grabber.
5.1.5.5

Take the Bridge Crane Out of Operation

1. Connect the smartphone (see Connect the Smartphone to Device Software on page 5-15) to the Bridge
Crane.
2. Select the page Put in operation
The page displays the current status.
3. Push the button
The page Bridge crane is displayed.
5.1.6

Shut Down the Vector and Disconnect from the Power

5.1.6.1 Shut Down the Vector and Disconnect from the Power
Only do this procedure when you do not want to use the Vector system for a longer
period and want to disconnect it from the power.
1. Set the main switch to Off (see figure 39 on page 5-9) on the power distribution box.
2. Open the power distribution box and disconnect the connector (1) (see figure 40 on page 5-10) to
disconnect the backup battery (2).
3. If the Feeding Robot is connected to the charger, manually drive the Feeding Robot backward to
disconnect from the charger.
4. If a second Feeding Robot is connected to the additional charger, manually drive the Feeding Robot
backward to disconnect from the charger.
5. Switch off the Mixing and Feeding Robot with the key (see figure 41 on page 5-11).
6. Remove the skirt piece and switch off the main switch of the Mixing and Feeding Robot (see figure 43
on page 5-13).
7. To prevent the tires from getting flat, put support blocks under the Mixing and Feeding Robot.
5-8
.
,
