Engine; Throttle Lever - Skyleader 200 Pilot Operating Handbook

88
2 333 371 B
7.4.

Engine

Enigne dates:
4-stroke, 4 cylinder horizontaly opposed, spark ignition engine, single central camshaft pull rods - OHV
Liquid cooled cylinder heads
Ram air cooled cylinders Engine type: Rotax 912ULS2
Dry sump forced lubrication Serial Number: 9 143 976
Dual breakerless capacitor discharge ignition
2 constant depression carburetors
Mechanical fuel pump
Electric starter (12V, 0.8W)
Integrated AC generator with external rectifier-regulator (12V, 20A DC)
Propeller drive via integrated gearbox with mechanical shock absorber and overload clutch

7.4.1. Throttle lever

The throttle lever is used for engine speed change. The throttle lever is installed on the top skin of cockpit tunnel
(between pilot and copilot seats). To increase the engine speed, push the throttle lever forward; to reduce the engine
speed, pull the throttle lever backwards.
Throttle lever
Increase RPM
Decrease RPM
KP 2U POH 05/2022
