14.5. MB- TP Module – for temperature compensation
The MB-TP module allows to use an isolated thermocouple type K (hot junction) or
PT100 sensor.
2 functions are then available: alarm or compensation.

14.5.1. Identification and configuration of the Temperature module MB-TP

14.5.2. Configuration of the temperature mode

After the identification described on the previous chapter, a new window is available
from the last page of the menu DEFINITION.
100
M1 – M3 AG
The temperature is
displayed
Selection between type
K or PT100
Unit : Degree Celsius or
Fahrenheit
