M1 – M3 AG

10.2. Command list

10.2.1. General Informations

Rubric Read. command
Software
version VER?
Device
serial
number SN?
Device
reference PN?

10.2.2. Window PART

Window « Part »
(Command by characteristic with "n" = 1 or 2 (number of the characteristic))
Rubric Read. command
Resolution nRES?
Unit nUNIT?
Dynamic mode nDYN?
Formula nFM?
Specific to taper
mode nND?
Direction nDIR?
Opening screen
Write command
Write command
CFG_ENTER
CFG-LEAVE
nRES=x
nUNIT=x
nDYN=x
nFM=x
nND=x
nDIR=x
Comment
ie : V3.30
ie : M32214522
ie : 13040
Comment
Locks characteristics display update
while display settings are changed
Unlocks characteristics display update
after display settings are changed
x=1 to 5 (number of decimals)
x=0(mm)
x=1 (inch)
x=2 (µm)
x=3 (DMS) degree_min_sec
x=4 (DEG) decimal degree
x=0 (static)
x=1 (maxi)
x=2 (mini)
x=3 (maxi-mini)
x=4 (average)
x=5 (median)
x=0 (C1)
x=1 (C2)
x=2 (-C1)
x=3 (-C2)
x=4 (C1+C2)
x=5 (C1-C2)
x=6 (-C1+C2)
x=7 (-C1-C2)
x=8 3 points C1
x=9 C points C2
x=10 (taper)
x=11 (half taper)
x=space between nozzle (taper)
x=0 (sans)
