M1 – M3 AG
4.2.

Air pipes

The M1/M3 are fitted with air connectors adapted to connected pipes with 6mm
external diameter and 4mm internal diameter.
In the case of the M3, it is however recommended to use an 8mm ext. tube from the
output of the air preparation unit to a Y connection/reduction to 6mm to the display.
We recommend using flexible pipes that prevent risk of fall or tilt over of the display
due to the orientation of the pipes. See the following picture.
