14.3. Module MB-RC (4 buttons command)

The MB-RC module is a box with 4 programmable buttons and is useful when a single
footswitch is not enough.
You can connect it to the output of a module.
Identify it from the MBUS menu and assign a function to each button. The list is
available below:
Fonction
Aucune
Transfer
Preset
Zero
Clear
Init Dyn
Hold
Characteristic
Touch screen
Description de la fonction
Transfer the measured value
Replaces the current measurement value with the master value
Set the displayed value to zero
Reset the dynamic measure
Start a dynamic measure
Freeze the measurement screen of the characteristic 1 or 2
Set the characteristic 1 or 2
Deactivate the touch screen function
