7.3.2. M-Bus modules

External M-Bus modules can be connected to the M1/M3 thanks to the following
screen.
It allows to mix 2 different probes on the same display with the multiplexer modules,
or to use input/output modules.
Multiplexer modules
The same process is made to connect all the multiplexer modules
Example : M1/M3 with MB-2S module (for Heidenhain probes) on the channel 2.
50
M1 – M3 AG
The probe
associated with
each channel can
be chosen here.
