Configuration; General Settings) - Metro DataVac M1 User Manual

7.4.

CONFIGURATION

After clicking on this button, the below window appears.
This window allows configuring the general settings of your M1/M3
7.4.1. Page 1 (general settings)
Footswitch functions are explained in the below table
When 2 functions are programed, a pressure on the
footswitch makes them happen one after each other.
Communication
function
Keyboard
54
Description
The M1/M3 is detected as a keyboard when connected to a
computer with a USB connection, without installing any specific
driver or software.
Then, when you transfer the measurement (from the touch screen,
MB-IO or the footswitch), the displayed value will appear on your
PC where your cursor is positioned. (For example, on an Excel cell),
the same way you would type with your standard keyboard.
M1 – M3 AG
Choice of the transfer
mode : RS232,
Keyboard or USB Stick
Language
selection. Other
languages can be
installed on
demand.
