Metro DataVac M1 User Manual page 90

List of available functions :
Function I/O
Transfer Input
Preset Input
Zero Input
Clear Input
Init Dyn Input
State Output
characteristic
Lower control Output
limit
Upper control Output
limit
Out Tol - Output
Out Tol + Output
Part status Output
Class Output
Stop Input
characteristic Input
Touchscreen Input
ECO mode Output
Footswitch Output
Activ Output
90
Description
Print, transfer the measured value
Set the display value to the master value
Set the display value to 0
Reset the dynamical measure
Start a dynamical measure
High/ Output a signal if the characteristic is in the
Low tolerance
High/ Output a signal if the part is below the lower control
Low limit
High/ Output a signal if the part is in above the upper
Low control limit
High/ Output a signal if the part is below the lower
Low tolerance
High/ Output a signal if the part is above the upper
Low tolerance
High/ Output a signal if the part is in the tolerances
Low
High/ Output a signal on a defined port for each class
Low
Hold the measure
Change the displayed characteristic
Disable the touch screen function
High/ Control of the automatic pressure reduction,
Low requires a regulator ref ACS-PNE-004 and the
cable 45186
High/ Trigger the active or inactive status of the module
Low depending on the state of the footswitch
(pushed/released)
OR Trigger the active or inactive status of the
module according to the impulse given by the
footswitch (toggled pushed/toggle released). It is
then possible, for example, to control the regulators
via a footswitch
High/ Indicate if the measurement screen is displayed, in
Low this case the measurements and the associated
states are valid
