Upper tolerance
Nominal
Lower tolerance
Master
Activate control
limits
Upper control limit
Lower control limit
Reference
Class
72
nUT? nUT=seee.ddddd
nUTD? nUTD=sdddDmmMssS
nNM? nNM=seee.ddddd
nNMD? nNMD=sdddDmmMssS
nLT? nLT=seee.ddddd
nLTD? nLTD=sdddDmmMssS
nMT? nMT=seee.ddddd
nM1? nM1=seee.ddddd
nM2? nM2=seee.ddddd
nLIMIT? nLIMIT=x
nUCL? nUCL=seee.ddddd
nUCLD? nUCLD=sdddDmmMssS
nLCL? nLCL=seee.ddddd
nLCLD? nLCLD=sdddDmmMssS
nREF? nREF=xxxxxxxx
CLASS CNT nn cc
CLASS SET nn cc Vmin
Vmax (DD in option)
CLASS GET nn
CNT
 cc (answer)
CLASS GET nn cc
 Vmin
Vmax DD
(answer)
M1 – M3 AG
x=1 (internal)
x=2 (external)
DMS display
Standard case
In case of dual master (for taper)
In case of dual master (for taper)
x=0 (inactive)
x=1 (active)
xxxxxxxx = part ref
Number of characteristic sort classes
nn : char. number (start from 1)
cc : number of class
One of the characteristic sort classes
nn : char. number (start from 1)
cc : class number
VMin: Value min (see.ddddd)
Vmax:Value max (see.ddddd)
DD (option) color number (between 0-
15)
Number of characteristic sort classes
nn : char. number (start from 1)
 cc : number of class
Config of one of the characteristic sort
classes
nn : char. number (start from 1)
cc class number (start from 1)
 VMin: Value min (see.ddddd)
 Vmax:Value max (see.ddddd)
 DD Color number (between 0-
15)
