M1 – M3 AG
The cabling schema is the following:
Regulation unit
ref ACS-PNE-003 (delivers
3BAR/0.3MPa pressure)
Air gage with by-pass nozzle
(integrated restrictor)
Stopper ref CMP-PNE-018
Standard push-in
connector, M5 thread.
Generally, for tube
external diam 3mm (ref
CMP-PNE-014)
19
