12.3. MB-TP Module – for temperature compensation
The MB-TP module allows to use an isolated thermocouple type K (hot junction) or
PT100 sensor.
2 functions are then available: alarm or compensation.
A – Identification and configuration of the Temperature module MB-TP
B – Configuration of the temperature mode
After the identification described on the previous chapter, a new window is available
from the last page of the menu DEFINITION.
Page 88
M1 – M3 Display units
The temperature is
displayed
Selection between type
K or PT100
Unit : Degree Celsius or
Fahrenheit
