7.1.
DEFINITION
After pressing on this icon, the bellow window appears:
It gives the possibility to define the resolution, unit, formula, tolerances, master
dimension, of each of the 2 available measurement configurations. The sorting
of parts into classes is also configurable from this window.
This window is divided in 2 parts for the configuration of the 2 characteristics,
and in 4 screens.
34
Go to the screen 1, 2, 3 or 4
M1 – M3 AG
Choice of the
characteristic 1 or 2
