18193 This cable allows to connect a M1 /M3 display to a
Multiplexer Mux from Metro, and to the DP1 printer
from Mitutoyo
45173 RS232/USB cable converter:
This cable allows a M1/M3 display to communicate
with a computer. It creates a virtual COM port on the
computer. The driver has to be downloaded from our
web-site Metro
password = metro)
ACS-AFF-
Tickets printer
Allows to print the displayed value of the M1/M3
002
+
Requires cable ref 45179 to be connected to the M1 /
45179
M3
ACS-AFF- QR code reader for Metro displays.
003
2 main functions:
- Allow to send a configuration on the display (part
definition, tolerance, display type, calibration of the air
gage, etc...)
- Send a Manufacturing order number. The export file
will take the name of the number entered.
