Hardware Installation and Reference Guide
1.3.6

Power Supply and Consumption

Table 1-9 Power Supply and Consumption
Power Supply
and
Consumption
Input power
supply
Maximum power
consumption
Caution
The power adapter is optional. If you need to use a DC power adapter for power supply, please purchase an
adapter that meets the corresponding safety requirements.
1.3.7

Environment and Reliability

Table 1-10 Environment and Reliability
Environment and
Reliability
Temperature
Humidity
Altitude
Mean Time Between
Failure (MTBF)
RG-AP810-I
The AP supports the following two power supply modes:
48 V DC/0.3 A power input over DC connector: The DC connector accepts 2.1
mm/5.5 mm center-positive circular plug. A DC power supply needs to be
purchased independently.
PoE input over LAN 1: The power source equipment (PSE) complies with IEEE
802.3af standard (PoE).
Note: If both DC power and PoE are available, DC power is preferred.
Maximum power consumption: 12.95 W
DC powered: 12.95 W
PoE++ powered (802.3bt): 12.95 W
PoE+ powered (802.3at): 12.95 W
PoE powered (802.3af): 12.95 W
Idle mode: 6 W
RG-AP810-I
Operating: -10° C to +50° C (14° F to 122° F)
Storage: -40° C to +70° C (-40° F to +158° F)
Note: At an altitude in the range of 1,800–4,000 m (5,905.51–13,123.36 ft.), every
time the altitude increases by 166 m (544.62 ft.), the maximum temperature
decreases by 1° C (1.8° F).
Operating: 5% to 95% (RH), non-condensing
Storage: 5% to 95% (RH), non-condensing
Operating altitude: –500 m to +4,000 m (–1,640.42 ft. to +13,123.36 ft.)
Storage altitude: –500 m to +5,000 m (–1640.42 ft. to +16,404.20 ft.)
200,000 hours (22 years) at the operating temperature of 25° C (77° F)
10
Product Overview
