Hardware Installation and Reference Guide
Wi-Fi Radio
802.11ax
Antenna
Transmit power
RG-AP810-I
Transmit beam-forming (TxBF)
Four spatial streams
Radio 1 – 2.4 GHz: 2x2 uplink/downlink MU-MIMO , two spatial streams
Radio 2 – 5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams
Channels:
Radio 1 – 2.4 GHz: 20 MHz and 40 MHz
Radio 2 – 5 GHz: 20 MHz, 40 MHz, and 80 MHz
Combined peak data rate: 1.775 Gbps
Radio 1 – 2.4 GHz: 8.6 Mbps to 0.574 Gbps (MCS0 to MCS11)
Radio 2 – 5 GHz: 8.6 Mbps to 1.201 Gbps (MCS0 to MCS11)
Radio technologies: uplink/downlink Orthogonal Frequency-Division Multiple Access
(OFDMA)
Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
Packet aggregation:
Aggregate MAC Protocol Data Unit (A-MPDU)
Aggregate MAC Service Data Unit (A-MSDU)
Dynamic Frequency Selection (DFS)
Cyclic Delay/Shift Diversity (CDD/CSD)
Maximum Ratio Combining (MRC)
Space-Time Block Coding (STBC)
Low-Density Parity Check (LDPC)
Transmit beam-forming (TxBF)
WPA3
Wi-Fi
2.4 GHz: two built-in omnidirectional antennas, with peak antenna gain of 2.8
dBi.
5 GHz: two built-in omnidirectional antennas, with peak antenna gain of 4.8 dBi.
Bluetooth
One onboard Bluetooth with built-in omnidirectional antenna, with peak antenna
gain of 2.4 dBi.
2.4 GHz:
Maximum transmit power: 26 dBm (398 mW)
5 GHz:
Maximum transmit power: 26 dBm (398 mW)
Note:
Adjusting the transmit power by percentage (recommended) and in 1 dBm
increments.
The transmit power is limited by local regulatory requirements. For details, see
WLAN Country or Region Codes and Channel
6
Product Overview
Compliance.
