Hardware Installation and Reference Guide
Anti-theft lock hole
1
2 Reset button
3 Console port
10/100/1000BASE-T Ethernet port
4
5 DC power plug
Note
The nameplate is at the bottom of the access point.
1.2

Package Contents

Table 1-3 Package Contents
Item
RG-AP810-I Access Point
Mounting Bracket
Wall Anchor
Phillips Pan Head Screws M4 x 20
Warranty Card
Quick Start Guide
1.3

Technical Specifications

1.3.1

Dimensions and Weight

Table 1-4 Dimensions and Weight
Dimensions and
Weight
Dimensions
(W x D x H)
Weight
Mounting
RG-AP810-I
Main unit: 220 mm x 220 mm x 49 mm (8.66 in. x 8.66 in. x 1.93 in.)
Shipping: 507 mm x 319 mm x 278 mm (19.96 in. x 12.56 in. x 10.74 in.)
Main unit: 0.6kg (1.33 lbs)
Mounting bracket: 0.07kg (0.15 lbs)
:
Shipping 1.04 kg (2.29 lbs)
Wall/Ceiling-mount (a mounting bracket is delivered with the main unit)
Connect to the anti-theft lock.
Reboot the device or restore the device to factory
settings.
Connect to the device that is managed with the serial
cable.
The uplink adaptive Ethernet port for service data
transmission.
IEEE 802.3af-compliant.
Connect to the DC power adapter to supply power to the
AP.
Quantity
1
1
4
4
1
1
3
Product Overview
