Technical Specifications And Product Parts; 92 Version - EK-Quantum Kinetic3 FLT Body PWM D-RGB Installation Manual

TECHNICAL SPECIFICATIONS AND PRODUCT PARTS

6
12
11
1
8
7
3
9
14
5
13
2
4
12

92 VERSION

Technical Specification:
- Dimensions: (L x H x W) – 92 x 118.5 x 47.5 mm
- D-RGB cable length: 500 mm
- D-RGB LED count: 14
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
Position EAN
1 107327
2 107333
3 107339
4 9040
5 100663
6 5154
7 105913
8 8311
9 107313
10 3831109834282
11 102639
12 8312
13 107341
14 103155
- 7 -
Description Quantity
TOP Plexi - Block FLT 92
TOP Plexi - Lid FLT 92
Mylar Label
Screw M3x28 DIN7991
EK Badge
OR 52 x 3
Pump holder
Screw M4 x 20 DIN7984
Pump holder
Plug Cover
EK-Plug G1/4
Screw M4 x 16 DIN7991
OR - FLT 92
LED Strip
1
1
1
2
1
1
1
4
1
5
5
10
1
1
