360 Version - EK-Quantum Kinetic3 FLT Body PWM D-RGB Installation Manual

Advertisement

12
11
10
1
4
5
2

360 VERSION

Technical Specification:
15
- Dimensions: (L x H x W) – 120 x 358.5 x 47.5 mm
7
- D-RGB cable length: 500 mm
- D-RGB LED count: 14
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
6
Position EAN
9
1
2
3
13
4
5
6
7
8
8
3
9
10
11
12
13
14
14
15
- 12 -
Description
107332
TOP Plexi - Block FLT 360
107338
TOP Plexi - Lid FLT 360
9040
Screw M3 x 28 DIN7991
102639
EK-Plug G1/4
3831109834282 Plug Cover
107324
LED Cover
107339
Mylar Label
107347
OR FLT 120
100663
EK Badge
5154
OR 52 x 3
105913
Pump holder
8311
Screw M4 x 20 DIN7984
107346
OR - Kinetic
8312
Screw M4 x 16 DIN7991
102711
LED Strip
Quantity
1
1
2
9
9
1
1
1
1
1
1
4
FLT 360
1
3
23
1
